103759 Series

Manufacturer: TE Connectivity AMP Connectors

Catalog

Catalog

CONN HEADER R/A 7POS 2.54MM

...

Part	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Contact Length - Mating	Contact Length - Mating	Contact Type	Insulation Height [z]	Insulation Height [z]	Number of Positions Loaded	Contact Length - Post	Contact Length - Post	Termination	Insulation Color	Contact Finish - Post	Contact Shape	Material Flammability Rating	Contact Finish - Mating	Fastening Type	Pitch - Mating	Pitch - Mating	Shrouding	Style	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Mounting Type	Contact Material	Operating Temperature [Max]	Operating Temperature [Min]	Number of Positions	Insulation Material	Connector Type	Current Rating (Amps)	Number of Rows
TE Connectivity AMP Connectors 4-103759-0-07	2.54 µm	100 µin	0.23 in	5.84 mm	Male Pin	3.5 mm	0.138 "	All	2.29 mm	0.09 in	Solder	Black	Tin-Lead	Square	UL94 V-0	Tin-Lead	Push-Pull	0.1 "	2.54 mm	Unshrouded	Board to Board Cable	100 çin	2.54 çm	Right Angle Through Hole	Copper Alloy	105 ░C	-65 ░C	7	Thermoplastic	Header Breakaway	3 A	1
TE Connectivity AMP Connectors 9-103759-0-12	2.54 µm	100 µin	0.23 in	5.84 mm	Male Pin	3.5 mm	0.138 "	All	2.29 mm	0.09 in	Solder	Black	Tin	Square	UL94 V-0		Push-Pull	0.1 "	2.54 mm	Unshrouded	Board to Board Cable	100 çin	2.54 çm	Right Angle Through Hole	Copper Alloy	105 ░C	-65 ░C	12	Thermoplastic	Header Breakaway	3 A	1
TE Connectivity AMP Connectors 4-103759-0-04	2.54 µm	100 µin	0.23 in	5.84 mm	Male Pin	3.5 mm	0.138 "	All	2.29 mm	0.09 in	Solder	Black	Tin-Lead	Square	UL94 V-0	Tin-Lead	Push-Pull	0.1 "	2.54 mm	Unshrouded	Board to Board Cable	100 çin	2.54 çm	Right Angle Through Hole	Copper Alloy	105 ░C	-65 ░C	4	Thermoplastic	Header Breakaway	3 A	1
TE Connectivity AMP Connectors 9-103759-0-13	2.54 µm	100 µin	0.23 in	5.84 mm	Male Pin	3.5 mm	0.138 "	All	2.29 mm	0.09 in	Solder	Black	Tin	Square	UL94 V-0		Push-Pull	0.1 "	2.54 mm	Unshrouded	Board to Board Cable	100 çin	2.54 çm	Right Angle Through Hole	Copper Alloy	105 ░C	-65 ░C	13	Thermoplastic	Header Breakaway	3 A	1
TE Connectivity AMP Connectors 4-103759-0-11	2.54 µm	100 µin	0.23 in	5.84 mm	Male Pin	3.5 mm	0.138 "	All	2.29 mm	0.09 in	Solder	Black	Tin-Lead	Square	UL94 V-0	Tin-Lead	Push-Pull	0.1 "	2.54 mm	Unshrouded	Board to Board Cable	100 çin	2.54 çm	Right Angle Through Hole	Copper Alloy	105 ░C	-65 ░C	11	Thermoplastic	Header Breakaway	3 A	1
TE Connectivity AMP Connectors 9-103759-0-21	2.54 µm	100 µin	0.23 in	5.84 mm	Male Pin	3.5 mm	0.138 "	All	2.29 mm	0.09 in	Solder	Black	Tin	Square	UL94 V-0		Push-Pull	0.1 "	2.54 mm	Unshrouded	Board to Board Cable	100 çin	2.54 çm	Right Angle Through Hole	Copper Alloy	105 ░C	-65 ░C	21	Thermoplastic	Header Breakaway	3 A	1
TE Connectivity AMP Connectors 4-103759-0-05	2.54 µm	100 µin	0.23 in	5.84 mm	Male Pin	3.5 mm	0.138 "	All	2.29 mm	0.09 in	Solder	Black	Tin-Lead	Square	UL94 V-0	Tin-Lead	Push-Pull	0.1 "	2.54 mm	Unshrouded	Board to Board Cable	100 çin	2.54 çm	Right Angle Through Hole	Copper Alloy	105 ░C	-65 ░C	5	Thermoplastic	Header Breakaway	3 A	1
TE Connectivity AMP Connectors 4-103759-0-30	2.54 µm	100 µin	0.23 in	5.84 mm	Male Pin	3.5 mm	0.138 "	All	2.29 mm	0.09 in	Solder	Black	Tin-Lead	Square	UL94 V-0	Tin-Lead	Push-Pull	0.1 "	2.54 mm	Unshrouded	Board to Board Cable	100 çin	2.54 çm	Right Angle Through Hole	Copper Alloy	105 ░C	-65 ░C	30	Thermoplastic	Header Breakaway	3 A	1
TE Connectivity AMP Connectors 9-103759-0-07	2.54 µm	100 µin	0.23 in	5.84 mm	Male Pin	3.5 mm	0.138 "	All	2.29 mm	0.09 in	Solder	Black	Tin	Square	UL94 V-0		Push-Pull	0.1 "	2.54 mm	Unshrouded	Board to Board Cable	100 çin	2.54 çm	Right Angle Through Hole	Copper Alloy	105 ░C	-65 ░C	7	Thermoplastic	Header Breakaway	3 A	1
TE Connectivity AMP Connectors 9-103759-0-04	2.54 µm	100 µin	0.23 in	5.84 mm	Male Pin	3.5 mm	0.138 "	All	2.29 mm	0.09 in	Solder	Black	Tin	Square	UL94 V-0		Push-Pull	0.1 "	2.54 mm	Unshrouded	Board to Board Cable	100 çin	2.54 çm	Right Angle Through Hole	Copper Alloy	105 ░C	-65 ░C	4	Thermoplastic	Header Breakaway	3 A	1
