307-074 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 74POS 0.156
| Part | Termination Rows [custom] | Material - Insulation | Operating Temperature [Min] | Operating Temperature [Max] | Card Thickness [Max] | Card Thickness [Min] | Contact Finish Thickness | Contact Finish Thickness | Features | Contact Type | Contact Material | Contact Finish | Number of Positions/Bay/Row | Card Type | Gender | Number of Rows [custom] | Pitch | Pitch | Color | Flange Feature | Read Out | Mounting Type | Termination | Number of Positions | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Polyester Thermoplastic | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Card Guides | Semi Bellows | Copper Alloy | Gold | 37 | Non Specified - Dual Edge | Female | 2 | 3.96 mm | 0.156 in | Green | 4-40 Flush Mount Threaded Insert Top Opening | Dual | Through Hole | Wire Wrap | 74 | ||
 EDAC Inc. | 2 | Polyester Thermoplastic | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Semi Bellows | Copper Alloy | Tin | 37 | Non Specified - Dual Edge | Female | 2 | 3.96 mm | 0.156 in | Green | Flush Mount M3 Threaded Insert Top Opening | Dual | Through Hole | Wire Wrap | 74 | |||||
 EDAC Inc. | 2 | Polyester Thermoplastic | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Card Extender | Semi Bellows | Copper Alloy | Gold | 37 | Non Specified - Dual Edge | Female | 2 | 3.96 mm | 0.156 in | Green | Flush Mount Side Opening Unthreaded | Dual | Board Edge Straddle Mount | Solder | 74 | 0.128 " | 3.25 mm |
 EDAC Inc. | 2 | Polyester Thermoplastic | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Card Guides | Semi Bellows | Copper Alloy | Gold | 37 | Non Specified - Dual Edge | Female | 2 | 3.96 mm | 0.156 in | Green | 4-40 Flush Mount Threaded Insert Top Opening | Dual | Right Angle Through Hole | Solder Wire Wrap | 74 | ||
 EDAC Inc. | 2 | Polyester Thermoplastic | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Card Guides | Semi Bellows | Copper Alloy | Gold | 37 | Non Specified - Dual Edge | Female | 2 | 3.96 mm | 0.156 in | Green | 4-40 Flush Mount Threaded Insert Top Opening | Dual | Through Hole | Solder | 74 | ||
 EDAC Inc. | 2 | Polyester Thermoplastic | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Semi Bellows | Copper Alloy | Gold | 37 | Non Specified - Dual Edge | Female | 2 | 3.96 mm | 0.156 in | Green | Dual | Through Hole | Solder | 74 | ||||
 EDAC Inc. | 2 | Polyester Thermoplastic | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Card Guides | Semi Bellows | Copper Alloy | Tin | 37 | Non Specified - Dual Edge | Female | 2 | 3.96 mm | 0.156 in | Green | 4-40 Flush Mount Threaded Insert Top Opening | Dual | Through Hole | Wire Wrap | 74 | ||||
 EDAC Inc. | 2 | Polyester Thermoplastic | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Semi Bellows | Copper Alloy | Gold | 37 | Non Specified - Dual Edge | Female | 2 | 3.96 mm | 0.156 in | Green | Flush Mount Top Opening Unthreaded | Dual | Right Angle Through Hole | Solder | 74 | 0.156 " | 3.96 mm | |
 EDAC Inc. | 2 | Polyester Thermoplastic | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Card Guides | Semi Bellows | Copper Alloy | Tin | 37 | Non Specified - Dual Edge | Female | 2 | 3.96 mm | 0.156 in | Green | 4-40 Flush Mount Threaded Insert Top Opening | Dual | Through Hole | Solder Eyelet(s) | 74 | ||||
 EDAC Inc. | 2 | Polyester Thermoplastic | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Semi Bellows | Copper Alloy | Tin | 37 | Non Specified - Dual Edge | Female | 2 | 3.96 mm | 0.156 in | Green | Dual | Through Hole | Solder | 74 |
