DD12.9321 Series

Catalog

PWR ENT MOD RCPT IEC320-C14 PNL

Part	Filter Type	Approval Agency	Connector Style	Accomodates a Fuse	Panel Thickness	Panel Thickness	Current Rating - Appliance Inlet	Mounting Type	Material Flammability Rating	Current Rating - Filter	Voltage Rating - Appliance Inlet	Fuse Holder, Drawer	Features	Termination	Termination	Termination	Switch Features	Panel Cutout Dimensions [x]	Panel Cutout Dimensions [y]	Connector Type	Ingress Protection	Panel Thickness [Max]	Panel Thickness [Max]	Panel Thickness [Min]	Panel Thickness [Min]
SCHURTER Inc. DD12.9321.111	Filtered (EMI RFI) - Commercial Medical	cURus ENEC	IEC 320-C14		8 mm	0.315 in	10 A	Flange Panel Mount	UL94 V-0	10 A	250 VAC	Drawer Sold Separate	Earth Line Choke Shielded V-Lock Notch	6.3 mm	Quick Connect	0.25 "	Switch On-Off	29.8 mm	49.3 mm	Receptacle Male Blades - Module	IP40
SCHURTER Inc. DD12.9321.131	Filtered (EMI RFI) - Commercial Medical	cURus ENEC	IEC 320-C14				10 A	Panel Mount Snap-In	UL94 V-0		250 VAC	Drawer Sold Separate	Earth Line Choke Shielded V-Lock Notch	6.3 mm	Quick Connect	0.25 "	Switch On-Off	29.8 mm	49.3 mm	Receptacle Male Blades - Module	IP40	0.118 in	3 mm	1 mm	0.039 in
