VI07 Series
Manufacturer: Amphenol Anytek
Beta
⌘K
TERM BLK 7POS SIDE ENT 7.5MM PCB
| Part | Mounting Type | Voltage | Positions Per Level | Operating Temperature [Min] | Operating Temperature [Max] | Wire Gauge [Min] | Wire Gauge [Max] | Mating Orientation | Number of Levels | Current | Pitch [x] | Pitch [x] | Wire Termination | Color | Housing Material | Torque - Screw | Torque - Screw | Clamp Material - Plating | Screw Thread | Features | Screw Material - Plating | Contact Material - Plating |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Amphenol Anytek | Through Hole | 300 V | 7 | -40 °C | 115 °C | 12 AWG | 28 AWG | Horizontal with Board | 1 | 16 A | 0.295 in | 7.5 mm | Screw - Rising Cage Clamp | Green | Thermoplastic | 0.4 Nm | 3.5 Lb-In | Brass - Nickel Plated | M3 | Interlocking (Side) | Steel Zinc Plated | |
 Amphenol Anytek | Through Hole | 300 V | 7 | -40 °C | 115 °C | 12 AWG | 28 AWG | Horizontal with Board | 1 | 16 A | 0.197 in | 5 mm | Screw - Rising Cage Clamp | Green | Thermoplastic | 0.4 Nm | 3.5 Lb-In | Copper Alloy - Nickel Plated | M3 | Interlocking (Side) | Steel Zinc Plated | Copper Alloy - Tin Plated |
 Amphenol Anytek | Through Hole | 300 V | 7 | -40 °C | 115 °C | 12 AWG | 28 AWG | Horizontal with Board | 1 | 16 A | 0.2 in | 5.08 mm | Screw - Rising Cage Clamp | Green | Thermoplastic | 0.4 Nm | 3.5 Lb-In | Copper Alloy - Nickel Plated | M3 | Interlocking (Side) | Steel Zinc Plated | Copper Alloy - Tin Plated |
Amphenol Anytek | Through Hole | 300 V | 7 | -40 °C | 115 °C | 12 AWG | 28 AWG | Vertical with Board | 1 | 16 A | 0.2 in | 5.08 mm | Screw - Rising Cage Clamp | Green | Thermoplastic | 0.4 Nm | 3.5 Lb-In | Brass - Nickel Plated | M3 | Interlocking (Side) | Steel Zinc Plated | |
Amphenol Anytek | Through Hole | 300 V | 7 | -40 °C | 115 °C | 12 AWG | 28 AWG | Vertical with Board | 1 | 16 A | 0.197 in | 5 mm | Screw - Rising Cage Clamp | Green | Thermoplastic | 0.4 Nm | 3.5 Lb-In | Brass - Nickel Plated | M3 | Interlocking (Side) | Steel Zinc Plated | |
Amphenol Anytek | Through Hole | 300 V | 7 | -40 °C | 115 °C | 12 AWG | 28 AWG | Horizontal with Board | 1 | 16 A | 0.197 in | 5 mm | Screw - Rising Cage Clamp | Green | Thermoplastic | 0.4 Nm | 3.5 Lb-In | Brass - Nickel Plated | M3 | Interlocking (Side) | Steel Zinc Plated | |
Amphenol Anytek | Through Hole | 300 V | 7 | -40 °C | 115 °C | 12 AWG | 28 AWG | Vertical with Board | 1 | 16 A | 0.2 in | 5.08 mm | Screw - Rising Cage Clamp | Green | Thermoplastic | 0.4 Nm | 3.5 Lb-In | Brass - Nickel Plated | M3 | Interlocking (Side) | Steel Zinc Plated |
