W5I-BO Series
Manufacturer: WIZnet
Beta
⌘K
ANTENNA PCB 2.5DBI GAIN 2483.5MHZ
| Part | Termination | Termination | Frequency (Center/Band) | Height (Max) [Max] [z] | Height (Max) [Max] [z] | VSWR | Features | Return Loss | Applications | Gain | Mounting Type | Antenna Type | Number of Bands | RF Family/Standard | Frequency Range [Min] | Frequency Range [Max] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 WIZnet | IPEX MHF1 | I-PEX MHF1 U.FL (UMCC) | 2.4 GHz | 0.039 in | 1 mm | 1.9 | Cable - 130mm | -22.36 dB | Bluetooth WLAN Zigbee™ | 2.5 dBi | Adhesive | PCB Trace | 1 | 802.15.4 Bluetooth WiFi | 2.4 GHz | 2.483 GHz |
