MN18TN Series
Manufacturer: NKK Switches
Beta
⌘K
FLAT FRAME MOUNT MINIATURE ROCKE
| Part | Electrical Life | Mechanical Life | Voltage Rating - DC | Actuator Marking | Panel Cutout Dimensions [y] | Panel Cutout Dimensions [x] | Actuator Type | Mounting Type | Switch Function | Operating Temperature [Max] | Operating Temperature [Min] | Color - Actuator/Cap | Termination Style | Circuit | Current Rating (Amps) | Approval Agency | Voltage Rating - AC |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NKK Switches | |||||||||||||||||
NKK Switches | |||||||||||||||||
 NKK Switches | 25000 Steps | 50000 Cycles | 30 V | No Marking | 10.1 mm | 17.8 mm | Paddle | Flange Panel Mount | Mom-Off-Mom | 85 °C | -30 ░C | Black | Solder Lug | SPDT | 3 A 6 A | UL | 125 V |
NKK Switches | |||||||||||||||||
NKK Switches | 25000 Steps | 50000 Cycles | 30 V | No Marking | 10.1 mm | 17.8 mm | Concave | Flange Panel Mount | Mom-Off-Mom | 85 °C | -30 ░C | Solder Lug | SPDT | 3 A 6 A | UL | 125 V | |
NKK Switches | 25000 Steps | 50000 Cycles | 30 V | No Marking | 12.4 mm | 0.5 in | Actuator Arm Cap Required | Flange Panel Mount | Mom-Off-Mom | 85 °C | -30 ░C | White | Solder Lug | SPDT | 3 A 6 A | UL | 125 V |
NKK Switches | |||||||||||||||||
 NKK Switches | |||||||||||||||||
NKK Switches | |||||||||||||||||
NKK Switches | 25000 Steps | 50000 Cycles | 30 V | No Marking | 12.4 mm | 0.5 in | Concave | Flange Panel Mount | Mom-Off-Mom | 85 °C | -30 ░C | Red | Solder Lug | SPDT | 3 A 6 A | UL | 125 V |
