EBCS10D Series
Manufacturer: Rosenberger
Beta
⌘K
COAX ADAPT EBC TO EBC
| Part | Operating Temperature [Min] | Operating Temperature [Max] | Center Contact Material | Body Material | Body Finish | Dielectric Material | Mating Cycles | Center Contact Plating | Center Gender | Adapter Type | Adapter Series | Convert To (Adapter End) | Frequency - Max [Max] | Conversion Type | Style | Fastening Type | Fastening Type | Mounting Type | Convert From (Adapter End) [custom] | Convert From (Adapter End) [custom] | Impedance |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Rosenberger | -55 C | 105 ░C | Copper Alloy | Brass | White Bronze | Polytetrafluoroethylene (PTFE) | 50 | Silver | Male to Male | Jack to Jack | EBC to EBC | EBC Jack Male Pin | 8 GHz | Same Series | Straight | Snap-On | Snap-On | Free Hanging (In-Line) | Male Pin | EBC Jack | 50 Ohms |
 Rosenberger | -55 C | 105 ░C | Copper Alloy | Brass | White Bronze | Polytetrafluoroethylene (PTFE) | 50 | Silver | Male to Male | Jack to Jack | EBC to EBC | EBC Jack Male Pin | 8 GHz | Same Series | Straight | Snap-On | Snap-On | Free Hanging (In-Line) | Male Pin | EBC Jack | 50 Ohms |
