PTC16 Series

Manufacturer: Sullins Connector Solutions

Catalog

CONN HEADER R/A 16POS 2.54MM

Part	Material Flammability Rating	Pitch - Mating	Pitch - Mating	Shrouding	Mounting Type	Number of Rows	Contact Shape	Contact Length - Post	Contact Length - Post	Termination	Current Rating (Amps)	Connector Type	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Insulation Color	Style	Contact Finish - Post	Insulation Material	Contact Material	Number of Positions	Contact Type	Number of Positions Loaded	Contact Length - Mating	Contact Length - Mating	Insulation Height	Insulation Height	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Fastening Type	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Overall Contact Length	Overall Contact Length	Number of Rows [custom]	Insulation Height [z]	Insulation Height [z]	Overall Contact Length	Overall Contact Length [x]	Overall Contact Length [x]
Sullins Connector Solutions PTC16SBAN	UL94 V-0	0.1 "	2.54 mm	Unshrouded	Right Angle Through Hole	1	Square	3.05 mm	0.12 in	Solder	3 A	Header	2.54 µm	100 µin	Black	Board to Board Cable	Tin	Polyester Thermoplastic	Copper Alloy	16	Male Pin	All	0.23 in	5.84 mm	3.56 mm	0.14 in	100 çin	2.54 çm	Push-Pull
Sullins Connector Solutions PTC16DABN	UL94 V-0	0.1 "	2.54 mm	Unshrouded	Through Hole		Square	5.84 mm	0.23 "	Solder	3 A	Header	2.54 µm	100 µin	Black	Board to Board Cable	Tin	Polyester Thermoplastic	Copper Alloy		Male Pin	All	0.23 in	5.84 mm	2.54 mm	0.1 in	100 çin	2.54 çm	Push-Pull	0.1 in	2.54 mm	0.56 in	14.22 mm	2
Sullins Connector Solutions PTC16DBEN	UL94 V-0	0.1 "	2.54 mm	Unshrouded	Right Angle Through Hole		Square	13.21 mm	0.52 in	Solder	3 A	Header	2.54 µm	100 µin	Black	Board to Board Cable	Tin	Polyester Thermoplastic	Copper Alloy		Male Pin	All	0.23 in	5.84 mm			100 çin	2.54 çm	Push-Pull	0.1 in	2.54 mm			2	6.1 mm	0.24 in
Sullins Connector Solutions PTC16DFCN	UL94 V-0	0.1 "	2.54 mm	Unshrouded	Through Hole		Square	8.13 mm	0.32 in	Solder	3 A	Header	2.54 µm	100 µin	Black	Board to Board Cable	Tin	Polyester Thermoplastic	Copper Alloy		Male Pin	All	0.318 in	8.08 mm	2.54 mm	0.1 in	100 çin	2.54 çm	Push-Pull	0.1 in	2.54 mm		18.75 mm	2			0.738 in
Sullins Connector Solutions PTC16SADN	UL94 V-0	0.1 "	2.54 mm	Unshrouded	Through Hole	1	Square	10.67 mm	0.42 in	Solder	3 A	Header	2.54 µm	100 µin	Black	Board to Board Cable	Tin	Polyester Thermoplastic	Copper Alloy	16	Male Pin	All	0.23 in	5.84 mm	2.54 mm	0.1 in	100 çin	2.54 çm	Push-Pull									19.05 mm	0.75 in
Sullins Connector Solutions PTC16SFBN	UL94 V-0	0.1 "	2.54 mm	Unshrouded	Through Hole	1	Square	5.58 mm	0.22 in	Solder	3 A	Header	2.54 µm	100 µin	Black	Board to Board Cable	Tin	Polyester Thermoplastic	Copper Alloy	16	Male Pin	All	0.318 in	8.08 mm	2.54 mm	0.1 in	100 çin	2.54 çm	Push-Pull			0.638 in	16.21 mm
Sullins Connector Solutions PTC16DACN	UL94 V-0	0.1 "	2.54 mm	Unshrouded	Through Hole		Square	8.13 mm	0.32 in	Solder	3 A	Header	2.54 µm	100 µin	Black	Board to Board Cable	Tin	Polyester Thermoplastic	Copper Alloy		Male Pin	All	0.23 in	5.84 mm	2.54 mm	0.1 in	100 çin	2.54 çm	Push-Pull	0.1 in	2.54 mm	0.65 in	16.51 mm	2
Sullins Connector Solutions PTC16SFEN	UL94 V-0	0.1 "	2.54 mm	Unshrouded	Through Hole	1	Square	13.21 mm	0.52 in	Solder	3 A	Header	2.54 µm	100 µin	Black	Board to Board Cable	Tin	Polyester Thermoplastic	Copper Alloy	16	Male Pin	All	0.318 in	8.08 mm	2.54 mm	0.1 in	100 çin	2.54 çm	Push-Pull			0.938 in	23.83 mm
Sullins Connector Solutions PTC16DADN	UL94 V-0	0.1 "	2.54 mm	Unshrouded	Through Hole		Square	10.67 mm	0.42 in	Solder	3 A	Header	2.54 µm	100 µin	Black	Board to Board Cable	Tin	Polyester Thermoplastic	Copper Alloy		Male Pin	All	0.23 in	5.84 mm	2.54 mm	0.1 in	100 çin	2.54 çm	Push-Pull	0.1 in	2.54 mm			2				19.05 mm	0.75 in
Sullins Connector Solutions PTC16SAHN	UL94 V-0	0.1 "	2.54 mm	Unshrouded	Through Hole	1	Square	20.83 mm	0.82 in	Solder	3 A	Header	2.54 µm	100 µin	Black	Board to Board Cable	Tin	Polyester Thermoplastic	Copper Alloy	16	Male Pin	All	0.23 in	5.84 mm	2.54 mm	0.1 in	100 çin	2.54 çm	Push-Pull			1.15 in	29.21 mm
