1546118 Series

Manufacturer: TE Connectivity AMP Connectors

Catalog

TERM BLOCK PLUG 12POS 270DEG 5MM

Part	Material Flammability Rating	Insulation Height	Insulation Height	Contact Material	Wire Strip Length [Max]	Wire Strip Length [Min]	Screw Size	Torque - Screw [Min]	Torque - Screw [Max]	Torque - Screw [Min]	Torque - Screw [Max]	Type	Termination Style	Positions Per Level	Plug Wire Entry [custom]	Voltage - UL	Wire Gauge or Range - AWG [Max]	Wire Gauge or Range - AWG [Min]	Pitch	Pitch	Number of Positions	Number of Levels	Operating Temperature [Min]	Operating Temperature [Max]	Wire Gauge or Range - mm² [Max]	Wire Gauge or Range - mm² [Min]	Contact Mating Finish	Mounting Type	Color	Features	Wire Gauge or Range - mm˛ [Max]	Wire Gauge or Range - mm˛ [Min]
TE Connectivity AMP Connectors 1-1546118-2	UL94 V-0	0.984 "	25 mm	Phosphor Bronze	7.5 mm	6 mm	M3	1.5 Nm	3 Nm	13.3 Lb-In	26.6 Lb-In	Plug Female Sockets	Screw - Rising Cage Clamp	12	270 °	300 V	30 AWG	12 AWG	0.197 in	5 mm	12	1	-40 C	110 °C	3 mm²	0.05 mm²	Tin	Free Hanging (In-Line)	Black
TE Connectivity AMP Connectors 3-1546118-6	UL94 V-0	0.984 "	25 mm	Phosphor Bronze	7.5 mm	6 mm	M3	1.5 Nm	3 Nm	13.3 Lb-In	26.6 Lb-In	Plug Female Sockets	Screw - Rising Cage Clamp	6	270 °	300 V	30 AWG	12 AWG	0.197 in	5 mm	6	1	-40 C	110 °C	3 mm²	0.05 mm²	Tin	Free Hanging (In-Line)	Black	Positions Stamped Retention Latches (Non-Wire Side)
TE Connectivity AMP Connectors 3-1546118-2	UL94 V-0	0.984 "	25 mm	Phosphor Bronze	7.5 mm	6 mm	M3	1.5 Nm	3 Nm	13.3 Lb-In	26.6 Lb-In	Plug Female Sockets	Screw - Rising Cage Clamp	22	270 °	300 V	30 AWG	12 AWG	0.197 in	5 mm	22	1	-40 C	110 °C	3 mm²	0.05 mm²	Tin	Free Hanging (In-Line)	Black	Positions Stamped Retention Latches (Non-Wire Side)	3 mm˛	0.05 mm˛
TE Connectivity AMP Connectors 1546118-4	UL94 V-0	0.984 "	25 mm	Phosphor Bronze	7.5 mm	6 mm	M3	1.5 Nm	3 Nm	13.3 Lb-In	26.6 Lb-In	Plug Female Sockets	Screw - Rising Cage Clamp	4	270 °	300 V	30 AWG	12 AWG	0.197 in	5 mm	4	1	-40 C	110 °C	3 mm²	0.05 mm²	Tin	Free Hanging (In-Line)	Black
