GLM65 Series
Manufacturer: SL POWER / Advanced Energy
Beta
⌘K
AC/DC CONVERTER 5V +/-12V 65W
| Part | Minimum Load Required | Voltage - Output 3 | Efficiency | Applications | Size / Dimension [x] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [z] | Type | Operating Temperature [Max] | Operating Temperature [Min] | Voltage - Output 2 | Features | Voltage - Input [Max] | Voltage - Input [Min] | Number of Outputs | Current - Output 2 | Current - Output 3 | Voltage - Output 1 | Mounting Type | Current - Output 1 | Approval Agency |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 SL POWER / Advanced Energy | -12 V | 80 % | Medical | 5 " | 127 mm | 76.2 mm | 31.8 mm | 3 " | 1.25 in | Open Frame | 50 °C | 0 °C | 12 V | Adjustable Output Remote Sense Universal Input | 264 VAC | 90 VAC | 3 | 3 A | 2.5 A | 5 V | Chassis Mount | 7 A | CE cURus TUV | |
 SL POWER / Advanced Energy | -15 V | 80 % | Medical | 5 " | 127 mm | 76.2 mm | 31.8 mm | 3 " | 1.25 in | Open Frame | 50 °C | 0 °C | 15 V | Adjustable Output Remote Sense Universal Input | 264 VAC | 90 VAC | 3 | 2.5 A | 2 A | 5.1 V | Chassis Mount | 7 A | CE cURus TUV |
