PHE426 Series

Manufacturer: KEMET

Catalog

Catalog

CAP FILM 10000PF 5% 630VDC RAD

...

Part	Dielectric Material	Lead Spacing	Lead Spacing	Package / Case	Tolerance	Applications	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Mounting Type	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Termination	Voltage Rating - AC	Operating Temperature [Min]	Operating Temperature [Max]	Capacitance	Height - Seated (Max) [Max] [z]	Voltage Rating - DC	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Size / Dimension [x]	Size / Dimension [y]	Height - Seated (Max) [Max]
KEMET PHE426MK5100JR05	Polypropylene (PP) Metallized	0.295 in	7.5 mm	Radial	5 %	DC Filtering DC Link DV/DT High Frequency High Pulse Switching	5 mm	0.197 "	10 mm	0.394 in	Through Hole	11 mm	0.433 in	PC Pins	250 V	-55 C	105 ░C	10000 pF
KEMET PHE426KJ4560JR05
KEMET PHE426HB7100JR06	Polypropylene (PP) Metallized	0.591 in	15 mm	Radial	5 %	DC Filtering DC Link DV/DT High Frequency High Pulse Switching	9.5 mm	0.374 in	18 mm	0.709 in	Through Hole	0.689 in		PC Pins	160 V	-55 C	105 ░C	1 µF	17.5 mm	250 V
KEMET PHE426MK4330JR05	Polypropylene (PP) Metallized	0.295 in	7.5 mm	Radial	5 %	DC Filtering DC Link DV/DT High Frequency High Pulse Switching	4 mm	0.157 "	10 mm	0.394 in	Through Hole			PC Pins	250 V	-55 C	105 ░C	0.0033 µF			8 mm	0.315 in
KEMET PHE426DJ5330FR17T0	Polypropylene (PP) Metallized	0.197 "	5 mm	Radial	1 %	DC Filtering DC Link DV/DT High Frequency High Pulse Switching	3.5 mm	0.138 in	7.2 mm	0.283 "	Through Hole			PC Pins	63 V	-55 C	105 ░C	0.033 çF		100 V	8 mm	0.315 in
KEMET PHE426RB5470JR06
KEMET PHE426KD6470JR06L2	Polypropylene (PP) Metallized	0.886 in	22.5 mm	Radial	5 %	DC Filtering DC Link DV/DT High Frequency High Pulse Switching	8 mm	0.315 in	26 mm	1.024 in	Through Hole	16 mm	0.63 in	PC Pins	220 V	-55 C	105 ░C	0.47 µF		400 V
KEMET PHE426HD7470JR06L2	Polypropylene (PP) Metallized	0.886 in	22.5 mm	Radial	5 %	DC Filtering DC Link DV/DT High Frequency High Pulse Switching	0.61 "		1.024 in		Through Hole			PC Pins	160 V	-55 C	105 ░C	4.7 µF		250 V	24.5 mm	0.965 in	26 mm	15.5 mm
KEMET PHE426HJ4270JR05	Polypropylene (PP) Metallized	0.197 "	5 mm	Radial	5 %	DC Filtering DC Link DV/DT High Frequency High Pulse Switching	2.5 mm	0.098 in	7.2 mm	0.283 "	Through Hole			PC Pins	160 V	-55 C	105 ░C	2700 pF		250 V	0.256 in				6.5 mm
KEMET PHE426DJ5470JR05	Polypropylene (PP) Metallized	0.197 "	5 mm	Radial	5 %	DC Filtering DC Link DV/DT High Frequency High Pulse Switching	3.5 mm	0.138 in	7.2 mm	0.283 "	Through Hole			PC Pins	63 V	-55 C	105 ░C			100 V	8 mm	0.315 in
