GLCA0 Series
Manufacturer: Honeywell Sensing and Productivity Solutions
Beta
⌘K
SWITCH SNAP ACTION DPST 6A 120V
| Part | Mechanical Life | Current Rating (Amps) | Operating Temperature [Max] | Operating Temperature [Min] | Operating Force | Overtravel | Operating Position | Features | Voltage Rating - DC | Actuator Type | Pretravel | Differential Travel | Switch Function | Termination Style | Mounting Type | Voltage Rating - AC | Ingress Protection | Overtravel | Operating Position | Circuit | Pretravel | Differential Travel | Circuit |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Honeywell Sensing and Productivity Solutions | 10000000 Cycles | 6 A 550 mA | 85 °C | -40 °C | 12 gfm | 49 ° | 26 ° | Steel Roller | 125 VDC | Roller Side Rotary | 26 ° | 12 ° | On-Mom | Screw Terminal | Chassis Mount | 120 V | IP67 - Dust Tight Waterproof | ||||||
 Honeywell Sensing and Productivity Solutions | 10000000 Cycles | 6 A 550 mA | 85 °C | -40 °C | 953 gf | 0.205 in | 1.409 in | 125 VDC | Lever Roller | 0.138 in | 0.05 in | On-Mom | Screw Terminal | Chassis Mount | 120 V | IP67 - Dust Tight Waterproof | 5.2 mm | 35.8 mm | SPDT | 3.5 mm | 1.3 mm | ||
Honeywell Sensing and Productivity Solutions | 10000000 Cycles | 6 A 550 mA | 85 °C | -40 °C | 12 gfm | 49 ° | 26 ° | Nylon Roller | 125 VDC | Roller Side Rotary | 26 ° | 12 ° | Off-Mom | Screw Terminal | Chassis Mount | 120 V | IP67 - Dust Tight Waterproof | DPST-NO | DM | ||||
 Honeywell Sensing and Productivity Solutions | 10000000 Cycles | 6 A 550 mA | 85 °C | -40 °C | 12 gfm | 49 ° | 26 ° | Nylon Roller | 125 VDC | Roller Side Rotary | 26 ° | 12 ° | On-Mom | Screw Terminal | Chassis Mount | 120 V | IP67 - Dust Tight Waterproof | SPDT | |||||
Honeywell Sensing and Productivity Solutions | 5000000 Cycles | 6 A 550 mA | 85 °C | -25 °C | 132 gf | 16 ° | 125 VDC | Cat Whisker Spring | 16 ° | 10 ° | On-Mom | Screw Terminal | Chassis Mount | 120 V | IP66 | SPDT |
