282843 Series

Catalog

TERM BLK 8P SIDE ENT 10.16MM PCB

Part	Torque - Screw	Torque - Screw	Pitch [x]	Pitch [x]	Voltage	Features	Clamp Material - Plating	Wire Termination	Screw Material - Plating	Wire Gauge [Max]	Wire Gauge [Min]	Current	Mounting Type	Screw Thread	Color	Positions Per Level	Mating Orientation	Contact Material - Plating [custom]	Number of Levels
TE Connectivity Raychem Cable Protection 282843-8	0.79 Nm	7 Lb-In	10.16 mm	0.4 in	600 V	Interlocking (Side)	Brass - Nickel Plated	Screw - Rising Cage Clamp	Brass - Nickel Plated	30 AWG	12 AWG	17.5 A	Through Hole	M3	Green	8	Horizontal with Board	Brass - Tin Plated	1
TE Connectivity Raychem Cable Protection 282843-9	0.79 Nm	7 Lb-In	10.16 mm	0.4 in	600 V	Interlocking (Side)	Brass - Nickel Plated	Screw - Rising Cage Clamp	Brass - Nickel Plated	30 AWG	12 AWG	17.5 A	Through Hole	M3	Green	9	Horizontal with Board	Brass - Tin Plated	1
TE Connectivity Raychem Cable Protection 282843-3	0.79 Nm	7 Lb-In	10.16 mm	0.4 in	600 V	Interlocking (Side)	Brass - Nickel Plated	Screw - Rising Cage Clamp	Brass - Nickel Plated	30 AWG	12 AWG	17.5 A	Through Hole	M3	Green	3	Horizontal with Board	Brass - Tin Plated	1
