500ASSP3 Series
Manufacturer: E-Switch
Beta
⌘K
SWITCH SLIDE SPDT 3A 120V
| Part | Switch Travel | Actuator Material | Electrical Life | Mechanical Life | Contact Timing | Features | Switch Function | Voltage Rating - AC | Current Rating (Amps) | Contact Finish | Operating Temperature [Max] | Operating Temperature [Min] | Mounting Type | Actuator Length [x] | Circuit | Termination Style | Contact Material | Actuator Type | Voltage Rating - DC |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 E-Switch | 3.05 mm | Polyamide (PA) Nylon | 30000 Cycles | 30000 Steps | Not Specified | Epoxy Sealed Terminals | On-Off-On | 120 V | 3 A | Silver | 85 °C | -30 ░C | Right Angle Through Hole | 3.1 mm | SPDT | PC Pin | Copper Alloy | Standard | 28 V |
 E-Switch | 3.05 mm | Polyamide (PA) Nylon | 30000 Cycles | 30000 Steps | Not Specified | Epoxy Sealed Terminals | On-Off-On | 20 V | 0.4 VA | Gold | 85 °C | -30 ░C | Right Angle Through Hole | 3.1 mm | SPDT | PC Pin | Copper Alloy | Standard | 20 V |
 E-Switch | 3.05 mm | Polyamide (PA) Nylon | 30000 Cycles | 30000 Steps | Not Specified | Epoxy Sealed Terminals | On-Off-On | 120 V | 3 A | Silver | 85 °C | -30 ░C | Through Hole | 3.1 mm | SPDT | PC Pin | Copper Alloy | Standard | 28 V |
 E-Switch | 3.05 mm | Polyamide (PA) Nylon | 30000 Cycles | 30000 Steps | Not Specified | Epoxy Sealed Terminals | On-Off-On | 20 V | 0.4 VA | Gold | 85 °C | -30 ░C | Through Hole | 3.1 mm | SPDT | PC Pin | Copper Alloy | Standard | 20 V |
E-Switch | 3.05 mm | Polyamide (PA) Nylon | 30000 Cycles | 30000 Steps | Not Specified | Epoxy Sealed Terminals | On-Off-On | 120 V | 3 A | Silver | 85 °C | -30 ░C | Right Angle Surface Mount | 3.1 mm | SPDT | Gull Wing | Copper Alloy | Standard | 28 V |
