316-024 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 56POS 0.156
| Part | Termination Rows | Material - Insulation | Card Thickness [Max] | Card Thickness [Min] | Operating Temperature [Min] | Operating Temperature [Max] | Termination | Card Type | Number of Positions | Features | Read Out | Contact Material | Contact Finish Thickness | Contact Finish Thickness | Contact Finish | Gender | Flange Feature | Mounting Type | Number of Positions/Bay/Row | Pitch | Pitch | Contact Type | Number of Rows [custom] | Color | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | Solder | Non Specified - Dual Edge | 56 | Card Guides | Dual | Copper Alloy | 0.25 Ám | 10 Áin | Gold | Female | 4-40 Flush Mount Threaded Insert Top Opening | Through Hole | 24 | 3.96 mm | 0.156 in | Cantilever | 2 | Green | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | Solder | Non Specified - Dual Edge | 56 | Dual | Copper Alloy | Tin | Female | Flush Mount Top Opening Unthreaded | Panel Mount Through Hole | 24 | 3.96 mm | 0.156 in | Cantilever | 2 | Green | 3.25 mm | 0.128 " | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | Solder Eyelet(s) | Non Specified - Dual Edge | 56 | Dual | Copper Alloy | Tin | Female | Flush Mount Top Opening Unthreaded | Panel Mount | 24 | 3.96 mm | 0.156 in | Cantilever | 2 | Green | 3.25 mm | 0.128 " | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | Solder Eyelet(s) | Non Specified - Dual Edge | 56 | Card Guides | Dual | Copper Alloy | Tin | Female | 4-40 Flush Mount Threaded Insert Top Opening | Panel Mount | 24 | 3.96 mm | 0.156 in | Cantilever | 2 | Green | ||||
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | Solder | Non Specified - Dual Edge | 56 | Dual | Copper Alloy | Tin | Female | Flush Mount Top Opening Unthreaded | Panel Mount Through Hole | 24 | 3.96 mm | 0.156 in | Cantilever | 2 | Green | 3.96 mm | 0.156 " | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | Solder Eyelet(s) | Non Specified - Dual Edge | 56 | Card Guides | Dual | Copper Alloy | Tin | Female | 4-40 Flush Mount Threaded Insert Top Opening | Panel Mount | 24 | 3.96 mm | 0.156 in | Cantilever | 2 | Green | ||||
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | Solder | Non Specified - Dual Edge | 56 | Card Guides | Dual | Copper Alloy | Tin | Female | 4-40 Flush Mount Threaded Insert Top Opening | Panel Mount Through Hole | 24 | 3.96 mm | 0.156 in | Cantilever | 2 | Green | ||||
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | Solder | Non Specified - Dual Edge | 56 | Dual | Copper Alloy | 0.25 Ám | 10 Áin | Gold | Female | Flush Mount Top Opening Unthreaded | Panel Mount Through Hole | 24 | 3.96 mm | 0.156 in | Cantilever | 2 | Green | 3.25 mm | 0.128 " | |
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | Solder Eyelet(s) | Non Specified - Dual Edge | 56 | Dual | Copper Alloy | Tin | Female | Free Hanging (In-Line) | 24 | 3.96 mm | 0.156 in | Cantilever | 2 | Green | ||||||
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | Solder Eyelet(s) | Non Specified - Dual Edge | 56 | Dual | Copper Alloy | 0.25 Ám | 10 Áin | Gold | Female | Flush Mount Top Opening Unthreaded | Panel Mount | 24 | 3.96 mm | 0.156 in | Cantilever | 2 | Green | 3.96 mm | 0.156 " |
