837-034 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 34POS 0.156
| Part | Termination Rows [custom] | Material - Insulation | Card Thickness [Max] | Card Thickness [Min] | Number of Positions/Bay/Row [custom] | Pitch | Pitch | Mounting Type | Contact Type | Termination | Color | Gender | Operating Temperature [Max] | Operating Temperature [Min] | Number of Rows [custom] | Contact Finish Thickness | Contact Finish Thickness | Read Out | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Contact Finish | Number of Positions [custom] | Contact Material | Card Type | Features | Termination Rows | Number of Positions/Bay/Row | Number of Rows |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 17 | 3.96 mm | 0.156 in | Through Hole | Cantilever | Solder Eyelet(s) | Green | Female | 125 °C | -40 C | 2 | 0.25 Ám | 10 Áin | Dual | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | Gold | 34 | Copper Alloy | Non Specified - Dual Edge | ||||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 17 | 3.96 mm | 0.156 in | Through Hole | Cantilever | Solder Eyelet(s) | Green | Female | 125 °C | -40 C | 2 | 0.25 Ám | 10 Áin | Dual | Floating Bobbin Top Mount Opening | 2.95 mm | 0.116 " | Gold | 34 | Copper Alloy | Non Specified - Dual Edge | ||||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 17 | 3.96 mm | 0.156 in | Board Edge Straddle Mount | Cantilever | Solder | Green | Female | 125 °C | -40 C | 2 | 0.25 Ám | 10 Áin | Dual | Gold | 34 | Copper Alloy | Non Specified - Dual Edge | Card Extender | ||||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | Through Hole | Cantilever | Solder | Green | Female | 125 °C | -40 C | 0.25 Ám | 10 Áin | Single | Flush Mount Side Opening Unthreaded | 3.25 mm | 0.128 " | Gold | 34 | Copper Alloy | Non Specified - Single Edge | 1 | 34 | 1 | ||||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 17 | 3.96 mm | 0.156 in | Through Hole | Cantilever | Solder | Green | Female | 125 °C | -40 C | 2 | 0.25 Ám | 10 Áin | Dual | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.156 " | Gold | 34 | Copper Alloy | Non Specified - Dual Edge | ||||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 17 | 3.96 mm | 0.156 in | Through Hole | Cantilever | Solder | Green | Female | 125 °C | -40 C | 2 | 0.25 Ám | 10 Áin | Dual | Flush Mount Side Opening Unthreaded | 3.25 mm | 0.128 " | Gold | 34 | Copper Alloy | Non Specified - Dual Edge | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | Through Hole | Cantilever | Wire Wrap | Green | Female | 125 °C | -40 C | 0.25 Ám | 10 Áin | Single | 3.25 mm | 0.128 " | Gold | 34 | Copper Alloy | Non Specified - Single Edge | 1 | 34 | 1 | |||||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 17 | 3.96 mm | 0.156 in | Through Hole | Cantilever | Solder | Green | Female | 125 °C | -40 C | 2 | 0.25 Ám | 10 Áin | Dual | 4-40 Flush Mount Threaded Insert Top Opening | Gold | 34 | Copper Alloy | Non Specified - Dual Edge | ||||||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 17 | 3.96 mm | 0.156 in | Board Edge Straddle Mount | Cantilever | Solder | Green | Female | 125 °C | -40 C | 2 | 0.25 Ám | 10 Áin | Dual | 4-40 Threaded Insert Top Mount Opening | Gold | 34 | Copper Alloy | Non Specified - Dual Edge | Card Extender | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | Through Hole | Cantilever | Solder | Green | Female | 125 °C | -40 C | 0.25 Ám | 10 Áin | Single | 3.96 mm | 0.156 " | Gold | 34 | Copper Alloy | Non Specified - Single Edge | 1 | 34 | 1 |
