1618274 Series

Manufacturer: TE Connectivity Aerospace, Defense and Marine

Catalog

HC-1/S122=RELAY, VACUUM, SPDT

Part	Termination Style	Coil Type	Operate Time	Seal Rating	Contact Form	Release Time	Operating Temperature [Min]	Operating Temperature [Max]	Relay Type	Contact Rating (Current)	Coil Voltage	Must Release Voltage	Coil Current	Must Operate Voltage	Contact Material	Switching Voltage [Max]	Coil Resistance
TE Connectivity Aerospace, Defense and Marine 1618274-6	Solder Turret	Non Latching	6 ms	Sealed - Vacuum	SPDT (1 Form C)	6 ms	-55 °C	125 °C	General Purpose	25 A
TE Connectivity Aerospace, Defense and Marine HC-4	Solder Turret	Non Latching	6 ms		SPDT (1 Form C)	6 ms	-55 °C	125 °C	General Purpose	15 A	26.5 VDC	1 VDC	79.1 mA	16 VDC	Tungsten (W)
TE Connectivity Aerospace, Defense and Marine HC-1	Solder Turret	Non Latching	6 ms	Sealed - Vacuum	SPDT (1 Form C)	6 ms	-55 °C	125 °C	General Purpose
TE Connectivity Aerospace, Defense and Marine HC-3	Solder Turret	Non Latching	6 ms		SPDT (1 Form C)	6 ms	-55 °C	125 °C	General Purpose	18 A	26.5 VDC	1 VDC	79.1 mA	16 VDC	Tungsten (W)	3500 VDC
TE Connectivity Aerospace, Defense and Marine 1-1618274-3	Solder Turret	Non Latching	6 ms	Sealed - Vacuum	SPDT (1 Form C)	6 ms	-55 °C	125 °C	General Purpose	25 A
TE Connectivity Aerospace, Defense and Marine 1618274-4	Solder Turret	Non Latching	6 ms	Sealed - Vacuum	SPDT (1 Form C)	6 ms	-55 °C	125 °C	General Purpose	25 A
TE Connectivity Aerospace, Defense and Marine HC-4/115VDC	Solder Turret	Non Latching	6 ms	Sealed - Vacuum	SPDT (1 Form C)	6 ms	-55 °C	125 °C	General Purpose	15 A	115 VDC	5 VDC	19.2 mA	80 VDC			6 kOhms
TE Connectivity Aerospace, Defense and Marine HC-1/12VDC	Solder Turret	Non Latching	6 ms	Sealed - Vacuum	SPDT (1 Form C)	6 ms	-55 °C	125 °C	General Purpose		12 VDC	5 VDC	150 mA	8 VDC			80 Ohms
