HEAVY DUTY CONNECTOR, PG16, HOOD, TOP ENTRY, ALUMINUM BODY, 1 LEVER, 10A

Part	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Connector Type	Housing Color	Style	Lock Location	Operating Temperature [Max]	Operating Temperature [Min]	Housing Finish	Size	Thread Size	Ingress Protection	Housing Material	Features	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]
HARTING 09200100440	67.2 mm	2.646 in	1.417 "	36 mm	2.469 in	62.7 mm	Hood	Gray	Top Entry	Locking Clip (1) on Base Bottom	125 °C	-40 C	Powder Coated	10 A	PG16	IP65 - Dust Tight Water Resistant	Aluminum Die Cast
HARTING 09200100730	2.441 in			1.417 in		2.469 in	Hood - Coupling	Gray	Bottom Entry Top or Bottom Entry	Locking Clip (1) on Hood Top	125 °C	-40 C	Powder Coated	10 A	PG16	IP65 - Dust Tight Water Resistant	Aluminum Die Cast	Cable to Cable	62 mm	36 mm	62.7 mm
HARTING 09200100321	26 mm	1.024 "	1.161 in	29.5 mm	3.189 in	81 mm	Base - Panel Mount	Gray	Bottom Entry	Locking Clip (1) on Base Bottom	125 °C	-40 C	Powder Coated	10 A		IP65 - Dust Tight Water Resistant	Aluminum Die Cast
HARTING 09200100251	52 mm	2.047 "	1.969 in	50 mm	2.929 "	74.4 mm	Base - Box Mount	Gray	Side Entry	Locking Clip (1) on Base Bottom	125 °C	-40 C	Powder Coated	10 A	PG16	IP65 - Dust Tight Water Resistant	Aluminum Die Cast
HARTING 09200100252	52 mm	2.047 "	1.969 in	50 mm	2.5 "	63.5 mm	Base - Box Mount	Gray	Side Entry	Locking Clip (1) on Base Bottom	125 °C	-40 C	Powder Coated	10 A	PG21	IP65 - Dust Tight Water Resistant	Aluminum Die Cast
HARTING 09200100731	2.441 in			1.417 in		2.469 in	Hood - Coupling	Gray	Bottom Entry Top or Bottom Entry	Locking Clip (1) on Hood Top	125 °C	-40 C	Powder Coated	10 A	PG21	IP65 - Dust Tight Water Resistant	Aluminum Die Cast	Cable to Cable	62 mm	36 mm	62.7 mm
HARTING 09200100680	67.2 mm	2.646 in	1.417 "	36 mm	2.469 in	62.7 mm	Hood		Dual Front Entry	Locking Clip (1) on Base Bottom				10 A	PG13.5
HARTING 09200100291	2.047 "			1.969 "		3.461 "	Base - Box Mount	Gray	Side Entry	Locking Clip (1) on Base Bottom	125 °C	-40 C	Powder Coated	10 A	PG16	IP65 - Dust Tight Water Resistant	Aluminum Die Cast	Feed Through	52 mm	50 mm	87.9 mm
HARTING 09200100540	67.2 mm	2.646 in	1.417 "	36 mm	2.469 in	62.7 mm	Hood	Gray	Side Entry	Locking Clip (1) on Base Bottom	125 °C	-40 C	Powder Coated	10 A	PG16	IP65 - Dust Tight Water Resistant	Aluminum Die Cast
HARTING 09200100441	82.2 mm	3.236 in	1.417 "	36 mm	2.469 in	62.7 mm	Hood	Gray	Top Entry	Locking Clip (1) on Base Bottom	125 °C	-40 C	Powder Coated	10 A	PG21	IP65 - Dust Tight Water Resistant	Aluminum Die Cast
