SDP3 Series
Manufacturer: SolaHD
Beta
⌘K
AC/DC DIN RAIL POWER SUPPLY (PSU), 1 OUTPUT, 51 W, 15 VDC, 4.2 A
| Part | Number of Outputs | Power (Watts) | DC Voltage - Input (Min) [Min] | DC Voltage - Input (Max) [Max] | Applications | Efficiency | Current - Output (Max) [Max] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [y] | Approval Agency | Operating Temperature [Max] | Operating Temperature [Min] | AC Voltage - Input [Max] | AC Voltage - Input [Min] | Voltage - Output 1 | Features | Input Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 SolaHD | 1 | 51 W | 90 V | 375 V | Hazardous Locations Industrial ITE (Commercial) | 86 % | 3.4 A | 3.58 in | 2.95 in | 74.9 mm | 1.77 in | 90.9 mm | 45 mm | CE cULus cURus | 70 °C | -10 °C | 264 VAC | 85 VAC | 15 V | Adjustable Output IP20 Universal Input | AC or DC |
