16_SMA-50 Series
Manufacturer: Huber+Suhner, Inc.
Beta
⌘K
RF CONNECTORS / COAXIAL CONNECTORS SMA RIGHT ANGLE CABLE PLUG(M)
| Part | Body Finish | Dielectric Material | Body Material | Mating Cycles | Center Contact Plating | Operating Temperature [Min] | Operating Temperature [Max] | Housing Color | Center Contact Material | Frequency - Max [Max] | Impedance | Contact Termination | Connector Type | Cable Group | Connector Style | Fastening Type | Number of Ports | Mounting Type | Shield Termination | Cable Group |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Huber+Suhner, Inc. | White Bronze | Polytetrafluoroethylene (PTFE) | Brass | 500 | Gold | -65 ░C | 165 °C | Silver | Brass | 18 GHz | 50 Ohms | Solder | Plug Male Pin | RG-58 303 | SMA | Threaded | 1 | Free Hanging (In-Line) Right Angle | Crimp | |
 Huber+Suhner, Inc. | White Bronze | Polytetrafluoroethylene (PTFE) | Brass | 500 | Gold | -65 ░C | 165 °C | Silver | Brass | 18 GHz | 50 Ohms | Solder | Plug Male Pin | RG-142 | SMA | Threaded | 1 | Free Hanging (In-Line) Right Angle | Crimp | 400 |
 Huber+Suhner, Inc. | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | Stainless Steel | 500 | Gold | -65 ░C | 165 °C | Silver | Beryllium Copper | 18 GHz | 50 Ohms | Solder | Plug Male Pin | 188 316 RG-174 | SMA | Threaded | 1 | Free Hanging (In-Line) Right Angle | Crimp | ||
 Huber+Suhner, Inc. | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | Stainless Steel | 500 | Gold | -65 ░C | 165 °C | Silver | Beryllium Copper | 18 GHz | 50 Ohms | Solder | Plug Male Pin | RG-142 | SMA | Threaded | 1 | Free Hanging (In-Line) Right Angle | Crimp | 400 | |
 Huber+Suhner, Inc. | Gold | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | Brass | 500 | Gold | -65 ░C | 165 °C | Gold | Beryllium Copper | 18 GHz | 50 Ohms | Solder | Plug Male Pin | RG-405 (.086 Semi Rigid) | SMA | Threaded | 1 | Free Hanging (In-Line) Right Angle | Solder | |
 Huber+Suhner, Inc. | Gold | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | Brass | 500 | Gold | -65 ░C | 165 °C | Gold | Beryllium Copper | 18 GHz | 50 Ohms | Solder | Plug Male Pin | RG-316 | SMA | Threaded | 1 | Free Hanging (In-Line) Right Angle | Crimp | |
 Huber+Suhner, Inc. | White Bronze | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | Beryllium Copper | 500 | Gold | -65 ░C | 165 °C | Silver | Brass | 18 GHz | 50 Ohms | Solder | Plug Male Pin | RG-141 | SMA | Threaded | 1 | Free Hanging (In-Line) Right Angle | Solder | |
 Huber+Suhner, Inc. | Polytetrafluoroethylene (PTFE) | Stainless Steel | 500 | Gold | -65 ░C | 165 °C | Silver | Beryllium Copper | 26.5 GHz | 50 Ohms | Crimp | Plug Male Pin | RG-141 | SMA | Threaded | 1 | Free Hanging (In-Line) Right Angle | Solder | ||
 Huber+Suhner, Inc. | White Bronze | Polytetrafluoroethylene (PTFE) | Brass | 500 | Gold | -65 ░C | 165 °C | Silver | Brass | 18 GHz | 50 Ohms | Solder | Plug Male Pin | RD-316 | SMA | Threaded | 1 | Free Hanging (In-Line) Right Angle | Crimp | |
 Huber+Suhner, Inc. | Gold | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | Beryllium Copper | 500 | Gold | -65 ░C | 165 °C | Gold | Beryllium Copper | 18 GHz | 50 Ohms | Solder | Plug Male Pin | RG-142 | SMA | Threaded | 1 | Free Hanging (In-Line) Right Angle | Crimp | 400 |
