MPX20 Series
Manufacturer: NXP USA Inc.
Beta
⌘K
SENSOR 7.25PSID 0.19" .04V
| Part | Port Style | Features | Operating Pressure | Port Diameter | Port Feature | Port Gender | Termination Style | Voltage - Supply (Maximum) | Voltage - Supply (Minimum) | Output Type | Mounting Type | Maximum Pressure | Output Voltage (Min) | Output Voltage (Max) | Package / Case | Pressure Type | Applications | Operating Temperature (Max) | Operating Temperature (Min) | Accuracy |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NXP USA Inc. | Barbed | Temperature Compensated | 7.25 PSI | 0.19 " | Dual Tube | Male | PC Pin | 16 V | 10 VDC | Wheatstone Bridge | Through Hole | 29.01 PSI | 0 mV | 40 mV | 4-SIP Module | Differential | Board Mount | 125 °C | -40 °C | |
 NXP USA Inc. | Barbed | Temperature Compensated | 7.25 PSI | 0.19 " | Tube | Male | PC Pin | 16 V | 10 VDC | Wheatstone Bridge | Through Hole | 29.01 PSI | 0 mV | 40 mV | 4-SIP Module | Vented Gauge | Board Mount | 125 °C | -40 °C | |
 NXP USA Inc. | Barbed | Temperature Compensated | 1.45 PSI | 0.19 " | Tube | Male | PC Pin | 16 V | 10 VDC | Wheatstone Bridge | Through Hole | 10.88 PSI | 0 mV | 25 mV | 4-SIP Module | Vented Gauge | Board Mount | 125 °C | -40 °C | 1 % |
