120-A-11 Series
Manufacturer: WECO Electrical Connectors Inc.
Coming soon—Zenode’s new Cross Ref’s tool! RSVP for the webinar here to get early access
Beta
⌘K
PLUG PLUG-IN SCREW; 3POS 5MM PIT
| Part | Housing Material | Contact Material | Wire Strip Length | Screw Size | Material Flammability Rating | Torque - Screw | Insulation Height | Pitch | Voltage - UL | Wire Gauge or Range - mm² | Termination Style | Features | Color | Current - UL | Mounting Type | Positions Per Level | Contact Mating Finish | Operating Temperature (Min) | Operating Temperature (Max) | Wire Gauge or Range - AWG (Min) | Wire Gauge or Range - AWG (Max) | Number of Levels | Number of Positions | Plug Wire Entry Angle | Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 WECO Electrical Connectors Inc. | Nylon PA Polyamide | Copper Alloy | 7 mm | M3 | UL94 V-0 | 0.51 Nm | 0.59 in | 0.197 in | 300 V | 2.5 mm² | Screw - Rising Cage Clamp | Retention Latches (Non-Wire Side) | Gray | 15 A | Free Hanging (In-Line) | 3 | Tin | -40 °C | 105 °C | 12 AWG | 25.5 AWG | 1 | 3 | 180 ° | Female Sockets Plug |
WECO Electrical Connectors Inc. | Nylon PA Polyamide | Copper Alloy | 7 mm | M3 | UL94 V-0 | 0.51 Nm | 0.59 in | 0.197 in | 300 V | 2.5 mm² | Screw - Rising Cage Clamp | Retention Latches (Non-Wire Side) | Gray | 15 A | Free Hanging (In-Line) | 6 | Tin | -40 °C | 105 °C | 12 AWG | 25.5 AWG | 1 | 6 | 180 ° | Female Sockets Plug |
