MS105A Series
Manufacturer: Littelfuse/Commercial Vehicle Products
Beta
⌘K
SWITCH SNAP ACTION
| Part | Voltage Rating - AC | Termination Style | Operating Position | Operating Position | Operating Temperature [Max] | Operating Temperature [Min] | Actuator Type | Current Rating (Amps) | Operating Force | Overtravel | Overtravel | Mounting Type | Circuit | Electrical Life | Mechanical Life | Pretravel | Pretravel | Switch Function |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Littelfuse/Commercial Vehicle Products | ||||||||||||||||||
Littelfuse/Commercial Vehicle Products | ||||||||||||||||||
 Littelfuse/Commercial Vehicle Products | 125 V | Solder Lug | 9.4 mm | 0.37 in | 85 °C | -40 °C | Round (Pin Plunger) | 5 A | 65 gf | 0.039 in | 1 mm | Chassis Mount | SPDT | 6000 Cycles | 1000000 Cycles | 0.118 in | 3 mm | On-Mom |
