837-070 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 70POS 0.156
| Part | Material - Insulation | Termination Rows [custom] | Contact Finish | Flange Feature | Operating Temperature [Max] | Operating Temperature [Min] | Termination | Gender | Number of Rows [custom] | Number of Positions | Color | Read Out | Card Type | Contact Material | Contact Type | Contact Finish Thickness | Contact Finish Thickness | Card Thickness [Max] | Card Thickness [Min] | Pitch | Pitch | Mounting Type | Number of Positions/Bay/Row | Features | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Gold | 4-40 Flush Mount Threaded Insert Top Opening | 125 °C | -40 C | Solder | Female | 2 | 70 | Green | Dual | Non Specified - Dual Edge | Copper Alloy | Cantilever | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | Board Edge Straddle Mount | 35 | Card Extender | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Gold | 4-40 Threaded Insert Top Mount Opening | 125 °C | -40 C | Solder | Female | 2 | 70 | Green | Dual | Non Specified - Dual Edge | Copper Alloy | Cantilever | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | Through Hole | 35 | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Gold | Flush Mount Side Opening Unthreaded | 125 °C | -40 C | Solder | Female | 2 | 70 | Green | Dual | Non Specified - Dual Edge | Copper Alloy | Cantilever | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | Right Angle Through Hole | 35 | 0.128 " | 3.25 mm | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Gold | 4-40 Flush Mount Threaded Insert Top Opening | 125 °C | -40 C | Solder | Female | 2 | 70 | Green | Dual | Non Specified - Dual Edge | Copper Alloy | Cantilever | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | Through Hole | 35 | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Gold | Side Mount Opening Unthreaded | 125 °C | -40 C | Solder | Female | 2 | 70 | Green | Dual | Non Specified - Dual Edge | Copper Alloy | Cantilever | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | Board Edge Straddle Mount | 35 | Card Extender | 0.128 " | 3.25 mm |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Gold | 125 °C | -40 C | Wire Wrap | Female | 2 | 70 | Green | Dual | Non Specified - Dual Edge | Copper Alloy | Cantilever | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | Through Hole | 35 | 0.156 " | 3.96 mm | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Gold | 4-40 Threaded Insert Top Mount Opening | 125 °C | -40 C | Solder | Female | 2 | 70 | Green | Dual | Non Specified - Dual Edge | Copper Alloy | Cantilever | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | Through Hole | 35 | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Gold | 4-40 Flush Mount Threaded Insert Top Opening | 125 °C | -40 C | Solder | Female | 2 | 70 | Green | Dual | Non Specified - Dual Edge | Copper Alloy | Cantilever | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | Through Hole | 35 | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Gold | 125 °C | -40 C | Solder | Female | 2 | 70 | Green | Dual | Non Specified - Dual Edge | Copper Alloy | Cantilever | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | Through Hole | 35 | 0.156 " | 3.96 mm | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Gold | 4-40 Threaded Insert Top Mount Opening | 125 °C | -40 C | Solder | Female | 2 | 70 | Green | Dual | Non Specified - Dual Edge | Copper Alloy | Cantilever | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | Board Edge Straddle Mount | 35 | Card Extender |
