039532 Series
Manufacturer: Molex
Beta
⌘K
TERM BLOCK HDR 20POS 5.08MM
| Part | Insulation Height | Insulation Height | Operating Temperature [Min] | Operating Temperature [Max] | Number of Positions | Termination Style | Color | Material Flammability Rating | Number of Levels | Contact Material | Mounting Type | Positions Per Level | Pitch [x] | Pitch [x] | Contact Mating Finish | Type | Contact Tail Length | Contact Tail Length | Voltage - UL | Header Orientation | Current - UL | Housing Material | Number of Positions |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Molex | 0.472 in | 12 mm | -40 °C | 105 ░C | 20 | Solder | Black | UL94 V-0 | 1 | Brass | Through Hole | 20 | 0.2 in | 5.08 mm | Tin | Header Male Pins Shrouded (4 Side) | 0.15 in | 3.81 mm | 300 V | 90° Right Angle | |||
 Molex | 0.327 " | 8.3 mm | -40 °C | 115 °C | 15 | Solder | Black | 1 | Brass | Through Hole | 15 | 0.2 in | 5.08 mm | Gold | Header Male Pins Shrouded (4 Side) | 0.17 in | 4.32 mm | 300 V | 90° Right Angle | 18 A | Polyamide (PA) Nylon | ||
 Molex | 0.327 " | 8.3 mm | -40 °C | 105 ░C | 6 | Solder | Green | UL94 V-0 | 1 | Brass | Through Hole | 6 | 0.2 in | 5.08 mm | Gold | Header Male Pins Shrouded (2 Side) | 0.15 in | 3.81 mm | 300 V | 90° Right Angle | |||
Molex | 0.472 in | 12 mm | -40 °C | 105 ░C | 13 | Solder | Black | UL94 V-0 | 1 | Brass | Through Hole | 13 | 0.2 in | 5.08 mm | Gold | Header Male Pins Shrouded (4 Side) | 0.15 in | 3.81 mm | 300 V | 90° Right Angle | |||
Molex | 0.472 in | 12 mm | -40 °C | 105 ░C | Solder | Green | UL94 V-0 | 1 | Brass | Through Hole | 3 | 0.2 in | 5.08 mm | Gold | Header Male Pins Shrouded (4 Side) | 0.15 in | 3.81 mm | 300 V | 90° Right Angle | ||||
Molex | 0.327 " | 8.3 mm | -40 °C | 115 °C | Solder | Black | 1 | Brass | Through Hole | 16 | 0.2 in | 5.08 mm | Tin | Header Male Pins Shrouded (4 Side) | 0.17 in | 4.32 mm | 300 V | 90° Right Angle | 18 A | Polyamide (PA) Nylon | 16 | ||
Molex | 0.327 " | 8.3 mm | -40 °C | 105 ░C | 23 | Solder | Black | UL94 V-0 | 1 | Brass | Through Hole | 23 | 0.2 in | 5.08 mm | Tin | Header Male Pins Shrouded (2 Side) | 0.15 in | 3.81 mm | 300 V | 90° Right Angle | |||
Molex | 0.327 " | 8.3 mm | -40 °C | 105 ░C | 13 | Solder | Black | UL94 V-0 | 1 | Brass | Through Hole | 13 | 0.2 in | 5.08 mm | Gold | Header Male Pins Shrouded (2 Side) | 0.15 in | 3.81 mm | 300 V | 90° Right Angle | |||
Molex | 0.472 in | 12 mm | -40 °C | 105 ░C | Solder | Green | UL94 V-0 | 1 | Brass | Through Hole | 17 | 0.2 in | 5.08 mm | Tin | Header Male Pins Shrouded (4 Side) | 0.15 in | 3.81 mm | 300 V | 90° Right Angle | ||||
 Molex | 0.472 in | 12 mm | -40 °C | 105 ░C | Solder | Green | UL94 V-0 | 1 | Brass | Through Hole | 16 | 0.2 in | 5.08 mm | Tin | Header Male Pins Shrouded (4 Side) | 0.15 in | 3.81 mm | 300 V | 90° Right Angle | 16 |
