562A032 Series

Catalog

MOLDED PARTS

Part	Small Diameter Recovered [diameter]	Small Diameter Recovered [diameter]	Shell Size - Insert	Small Diameter Supplied [diameter]	Small Diameter Supplied [diameter]	Large Diameter Supplied [diameter]	Large Diameter Supplied [diameter]	Type	Large Diameter Recovered [diameter]	Large Diameter Recovered [diameter]	Color	Large Recovered Length	Large Recovered Length	Material	Small Recovered Length	Small Recovered Length [x]	Large Recovered Length
TE Connectivity Aerospace, Defense and Marine 562A032-25-G03/225-0	0.27 "	6.86 mm	32	0.52 in	13.21 mm	0.76 in	19.3 mm	Boot Transition - Breakout 4:1	0.38 in	9.65 mm	Black	1.42 in	36.07 mm	Elastomer Fluid Resistant	44.96 mm	1.77 in
TE Connectivity Aerospace, Defense and Marine 562A032-100/180-0	0.27 "	6.86 mm	32	0.52 in	13.21 mm	0.76 in	19.3 mm	Boot Transition - Breakout 4:1	0.38 in	9.65 mm	Black	1.42 in	36.07 mm	Polyolefin (PO) Semi-Flexible Halogen Free	44.96 mm	1.77 in
TE Connectivity Aerospace, Defense and Marine 562A032-25/42-0	0.27 "	6.86 mm	32	0.52 in	13.21 mm	0.76 in	19.3 mm	Boot Transition - Breakout 4:1	0.38 in	9.65 mm	Black	1.42 in	36.07 mm	Elastomer Fluid Resistant	44.96 mm	1.77 in
TE Connectivity Aerospace, Defense and Marine 562A032-25-0	0.272 "	6.91 mm	32	0.52 in	13.21 mm	0.76 in	19.3 mm	Boot Transition - Breakout 4:1	0.382 in	9.7 mm	Black	36.09 mm		Elastomer Semi-Rigid	44.96 mm	1.77 in	1.421 in
