CLU044 Series

Catalog

LED COB LIGHT PINK SQUARE

Part	Luminous Flux @ Current/Temperature	Size / Dimension [y]	Size / Dimension [x]	Current - Test	Height [z]	Configuration	Light Emitting Surface (LES) [diameter]	Type	Current - Max [Max]	Lumens/Watt @ Current - Test	Voltage - Forward (Vf) (Typ)	Color	Temperature - Test	Lens Type	CRI (Color Rendering Index)
Citizen Finedevice Co Ltd CLU044-1212B8-LPGV1F7	2632 lm	28 mm	28 mm	1.08 A	1.4 mm	Square	22 mm	Chip On Board (COB)	2.16 A	68 lm/W	35.7 V	Pink	25 °C	Flat
Citizen Finedevice Co Ltd CLU044-1212B8-32GV1F6	3948 lm	28 mm	28 mm	1.08 A	1.4 mm	Square	22 mm	Chip On Board (COB)	2.16 A	102 lm/W	35.7 V	Warm White	25 °C	Flat	95
Citizen Finedevice Co Ltd CLU044-1812B8-LPGV1F7	3682 lm	28 mm	28 mm	1.08 A	1.4 mm	Square	22 mm	Chip On Board (COB)	2.16 A	64 lm/W		Pink	25 °C	Flat
