892-017 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 17POS 0.100
| Part | Termination Rows | Material - Insulation | Gender | Color | Contact Finish Thickness | Contact Finish Thickness | Read Out | Number of Positions/Bay/Row [custom] | Card Type | Operating Temperature [Max] | Operating Temperature [Min] | Number of Rows | Card Thickness [Max] | Card Thickness [Min] | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Termination | Pitch | Pitch | Mounting Type | Contact Type | Contact Material | Contact Finish |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Female | Black | 0.25 Ám | 10 Áin | Single | 17 | Non Specified - Single Edge | 125 °C | -40 C | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Wire Wrap | 0.1 " | 2.54 mm | Through Hole | Cantilever | Copper Alloy | Gold |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Female | Black | 0.25 Ám | 10 Áin | Single | 17 | Non Specified - Single Edge | 125 °C | -40 C | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Flush Mount M3 Threaded Insert Top Opening | Solder | 0.1 " | 2.54 mm | Right Angle Through Hole | Cantilever | Copper Alloy | Gold | ||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Female | Black | 0.25 Ám | 10 Áin | Single | 17 | Non Specified - Single Edge | 125 °C | -40 C | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 4-40 Flush Mount Threaded Insert Top Opening | Wire Wrap | 0.1 " | 2.54 mm | Through Hole | Cantilever | Copper Alloy | Gold | ||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Female | Black | 0.25 Ám | 10 Áin | Single | 17 | Non Specified - Single Edge | 125 °C | -40 C | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Wire Wrap | 0.1 " | 2.54 mm | Through Hole | Cantilever | Copper Alloy | Gold | |||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Female | Black | 0.25 Ám | 10 Áin | Single | 17 | Non Specified - Single Edge | 125 °C | -40 C | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 4-40 Flush Mount Threaded Insert Top Opening | Solder | 0.1 " | 2.54 mm | Through Hole | Cantilever | Copper Alloy | Gold | ||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Female | Black | 0.25 Ám | 10 Áin | Single | 17 | Non Specified - Single Edge | 125 °C | -40 C | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | 0.1 " | 2.54 mm | Right Angle Through Hole | Cantilever | Copper Alloy | Gold | |||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Female | Black | 0.25 Ám | 10 Áin | Single | 17 | Non Specified - Single Edge | 125 °C | -40 C | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | Wire Wrap | 0.1 " | 2.54 mm | Through Hole | Cantilever | Copper Alloy | Gold |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Female | Black | 0.25 Ám | 10 Áin | Single | 17 | Non Specified - Single Edge | 125 °C | -40 C | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Solder | 0.1 " | 2.54 mm | Right Angle Through Hole | Cantilever | Copper Alloy | Gold |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Female | Black | 0.25 Ám | 10 Áin | Single | 17 | Non Specified - Single Edge | 125 °C | -40 C | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Solder | 0.1 " | 2.54 mm | Through Hole | Cantilever | Copper Alloy | Gold |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Female | Black | 0.25 Ám | 10 Áin | Single | 17 | Non Specified - Single Edge | 125 °C | -40 C | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | Wire Wrap | 0.1 " | 2.54 mm | Through Hole | Cantilever | Copper Alloy | Gold |
