Rocker Switches L24E3S001AZZ00000
Rocker Switches L24E3S001AZZ00000
| Part | Illumination Type, Color | Ingress Protection | Illumination Voltage (Nominal) | Mechanical Life | Current Rating (Amps) | Actuator Marking | Mounting Type | Termination Style | Voltage Rating - DC | Actuator Type | Panel Cutout Dimensions [x] | Panel Cutout Dimensions [y] | Circuit | Switch Function | Operating Temperature [Max] | Operating Temperature [Min] | Color - Actuator/Cap | Electrical Life |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Carling Technologies | Green LED | IP67 - Dust Tight Waterproof | 12 VDC | 100000 Cycles | 20 A | No Marking | Panel Mount Snap-In | Quick Connect - 0.250" (6.3mm) | 12 V | Concave (Curved) - Illuminated | 44.04 mm | 22.02 mm | SPST | On-Off | 85 °C | -40 °C | Black | 100000 Cycles |
Carling Technologies | Green LED | IP67 - Dust Tight Waterproof | 12 VDC | 100000 Cycles | 20 A | Low Beam Vertical | Panel Mount Snap-In | Quick Connect - 0.250" (6.3mm) | 12 V | Concave (Curved) - Illuminated | 44.04 mm | 22.02 mm | SPST | On-Off | 85 °C | -40 °C | 100000 Cycles | |
 Carling Technologies | IP67 - Dust Tight Waterproof | 15 A | No Marking | Panel Mount Snap-In | Quick Connect - 0.250" (6.3mm) | 12 V | Concave (Curved) | 44.04 mm | 22.02 mm | SPDT | On-Off-Mom | 85 °C | -40 °C | Black | 50000 Cycles | |||
Carling Technologies | Green LED | IP67 - Dust Tight Waterproof | 12 VDC | 100000 Cycles | 20 A | Low Beam Vertical | Panel Mount Snap-In | Quick Connect - 0.250" (6.3mm) | 12 V | Concave (Curved) - Illuminated | 44.04 mm | 22.02 mm | SPST | On-Off | 85 °C | -40 °C | 100000 Cycles | |
Carling Technologies | Amber/Amber LED | IP67 - Dust Tight Waterproof | 12 VDC | 100000 Cycles | 20 A | Low Beam Vertical | Panel Mount Snap-In | Quick Connect - 0.250" (6.3mm) | 12 V | Concave (Curved) - Illuminated | 44.04 mm | 22.02 mm | SPST | On-Off | 85 °C | -40 °C | Black | 100000 Cycles |
Carling Technologies | Green LED | IP67 - Dust Tight Waterproof | 12 VDC | 100000 Cycles | 20 A | No Marking | Panel Mount Snap-In | Quick Connect - 0.250" (6.3mm) | 12 V | Concave (Curved) - Illuminated | 44.04 mm | 22.02 mm | SPST | On-Off | 85 °C | -40 °C | Black | 100000 Cycles |
Carling Technologies | Green LED | IP67 - Dust Tight Waterproof | 12 VDC | 100000 Cycles | 20 A | Low Beam Vertical | Panel Mount Snap-In | Quick Connect - 0.250" (6.3mm) | 12 V | Concave (Curved) - Illuminated | 44.04 mm | 22.02 mm | SPST | On-Off | 85 °C | -40 °C | 100000 Cycles | |
Carling Technologies | IP67 - Dust Tight Waterproof | 15 A | No Marking | Panel Mount Snap-In | Quick Connect - 0.187" (4.7mm) | 12 V | Concave (Curved) | 44.04 mm | 22.02 mm | DPDT | Mom-Off-Mom | 85 °C | -40 °C | 50000 Cycles | ||||
 Carling Technologies | Green/Green LED | IP67 - Dust Tight Waterproof | 12 VDC | 20 A | Low Beam Horizontal | Panel Mount Snap-In | Quick Connect - 0.250" (6.3mm) | 12 V | Paddle - Illuminated | 44.04 mm | 22.02 mm | DPDT | Mom-Off-Mom | 85 °C | -40 °C | 50000 Cycles | ||
Carling Technologies | IP67 - Dust Tight Waterproof | 20 A | Low Beam Vertical | Panel Mount Snap-In | Quick Connect - 0.250" (6.3mm) | 12 V | Concave (Curved) | 44.04 mm | 22.02 mm | DPDT | Mom-Off-Mom | 85 °C | -40 °C | Black | 50000 Cycles |
