Charge Controllers EV-CC-AC1-M3-CC-SER PCB -

Manufacturer: Panduit Corp

Catalog

Charge Controllers EV-CC-AC1-M3-CC-SER PCB -

Catalog

Charge Controllers EV-CC-AC1-M3-CC-SER PCB -

Part	Insulation	Length - Overall [x]	Length - Overall [x]	Contact Material	Material - Insulation	Length - Pin [x]	Length - Pin [x]	Insulation Diameter	Insulation Diameter	Wire Gauge [Max]	Wire Gauge [Min]	Contact Finish	Pin Diameter	Pin Diameter	Features	Color	Termination	Stud/Tab Size	Thickness	Thickness	Terminal Type	Width - Outer Edges	Width - Outer Edges [y]	Mounting Type	Stud/Tab Size	Tongue Inside Opening [x]	Tongue Inside Opening [x]	Width - Outer Edges [y]	Length - Overall	Length - Overall	Length - Ring Center to Termination [x]	Length - Ring Center to Termination [x]	Length - Termination [x]	Length - Termination [x]	Insulation Diameter [diameter]
Panduit Corp EV18-P47B-Q	Insulated	0.97 in	24.64 mm	Copper	Vinyl	0.49 in	12.45 mm	3.81 mm	0.15 in	22 AWG	17.5 AWG	Tin	1.78 mm	0.07 "	Brazed Seam	Red	Crimp
Panduit Corp EV18-56RB-L	Insulated			Copper	Vinyl			3.81 mm	0.15 in	22 AWG	17.5 AWG	Tin			Butted Seam	Red	Crimp	0.3125 Stud	0.81 mm	0.032 in	Circular	11.68 mm	0.46 in	Free Hanging (In-Line)
Panduit Corp EV18-8LFB-L	Insulated	0.97 in	24.64 mm	Copper	Vinyl			3.81 mm	0.15 in	22 AWG	17.5 AWG	Tin			Butted Seam Serrated Termination	Red	Crimp				Snap Spring		0.29 in	Free Hanging (In-Line)	8 Stud	0.16 in	4.06 mm	7.37 mm
Panduit Corp EV18-6LFB-L	Insulated			Copper	Vinyl			3.81 mm	0.15 in	22 AWG	17.5 AWG	Tin			Butted Seam Serrated Termination	Red	Crimp	6 Stud			Snap Spring		0.27 in	Free Hanging (In-Line)		0.14 in	3.56 mm	6.86 mm	0.9 in	22.86 mm
Panduit Corp EV18-6LFB-Q	Insulated			Copper	Vinyl			3.81 mm	0.15 in	22 AWG	17.5 AWG	Tin			Butted Seam Serrated Termination	Red	Crimp	6 Stud			Snap Spring		0.27 in	Free Hanging (In-Line)		0.14 in	3.56 mm	6.86 mm	0.9 in	22.86 mm
Panduit Corp EV18-14FB-Q	Insulated	0.83 in		Copper	Vinyl				3.68 mm	22 AWG	16 AWG	Tin			Butted Seam	Red	Crimp	0.25 Stud			Standard		0.37 in	Free Hanging (In-Line)		0.25 in	6.35 mm	9.4 mm		21.08 mm	0.26 in	6.6 mm	9.91 mm	0.39 in	0.145 "
Panduit Corp EV18-56RB-Q	Insulated			Copper	Vinyl			3.81 mm	0.15 in	22 AWG	17.5 AWG	Tin			Butted Seam	Red	Crimp	0.3125 Stud	0.81 mm	0.032 in	Circular	11.68 mm	0.46 in	Free Hanging (In-Line)
Panduit Corp EV18-6FB-L	Insulated	0.86 "	21.84 mm	Copper	Vinyl			3.81 mm	0.15 in	22 AWG	17.5 AWG	Tin			Butted Seam	Red	Crimp	6 Stud			Standard			Free Hanging (In-Line)		0.15 in	3.81 mm
Panduit Corp EV18-10LFB-Q	Insulated	0.97 in	24.64 mm	Copper	Vinyl			3.81 mm	0.15 in	22 AWG	17.5 AWG	Tin			Butted Seam Serrated Termination	Red	Crimp	10 Stud			Snap Spring		0.33 in	Free Hanging (In-Line)		0.19 in	4.83 mm	8.38 mm
Panduit Corp EV18-8FB-Q	Insulated	0.93 in		Copper	Vinyl			3.81 mm	0.15 in	22 AWG	17.5 AWG	Tin			Butted Seam	Red	Crimp				Standard		0.32 in	Free Hanging (In-Line)	8 Stud	0.17 in	4.32 mm	8.13 mm		23.62 mm
