09300161 Series

Manufacturer: HARTING

Catalog

HEAVY DUTY CONNECTOR, BASE, BULKHEAD MOUNT, ALUMINUM BODY, 1 LEVER, 16B

Part	Connector Type	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Housing Finish	Lock Location	Housing Material	Size	Housing Color	Style	Operating Temperature [Max]	Operating Temperature [Min]	Ingress Protection	Size / Dimension [y]	Size / Dimension [z]	Thread Size	Features	Frame Type
HARTING 09300161307	Base - Panel Mount	30.2 mm	4.646 in	1.189 "	48.4 mm	118 mm	1.906 "	Powder Coated	Locking Clip (1) on Base Bottom	Aluminum Die Cast	16 B	Gray	Bottom Entry	125 °C	-40 C	IP65 IP67
HARTING 09300161290	Base - Box Mount		4.606 in	2.197 in		117 mm	2.244 "	Powder Coated	Locking Clip (1) on Base Bottom	Aluminum Die Cast	16 B	Gray	Side Entry	125 °C	-40 C	IP65 - Dust Tight Water Resistant	57 mm	55.8 mm	PG21	Feed Through
HARTING 09300161520	Hood	2.461 in 62.5 mm			1.693 " 43 mm	3.681 in 93.5 mm		Powder Coated	Locking Clip (2) on Base Bottom	Aluminum Die Cast	16 B	Gray	Side Entry	125 °C	-40 C	IP65 - Dust Tight Water Resistant			PG21
HARTING 09300161530	Hood	2.461 in 62.5 mm			1.693 " 43 mm	3.681 in 93.5 mm		Powder Coated	Locking Clip (2) on Hood	Aluminum Die Cast	16 B	Gray	Side Entry	125 °C	-40 C	IP65 - Dust Tight Water Resistant			PG21
HARTING 09300161703											16 B										Fixed Frame
HARTING 09300161308	Base - Panel Mount	31.3 mm	4.646 in	1.232 in	48.4 mm	118 mm	1.906 "	Powder Coated	Locking Clip (1) on Base Bottom	Aluminum Die Cast	16 B	Gray	Bottom Entry	125 °C	-40 C	IP65 IP67				Cover
HARTING 09300161540	Hood	2.461 in 62.5 mm			1.693 " 43 mm	3.681 in 93.5 mm		Powder Coated	Locking Clip (1) on Base Bottom	Aluminum Die Cast	16 B	Gray	Side Entry	125 °C	-40 C	IP65 - Dust Tight Water Resistant			PG21
HARTING 09300161430	Hood	45 mm	3.681 in	1.772 in	43 mm	93.5 mm	1.693 "	Powder Coated	Locking Clip (2) on Hood	Aluminum Die Cast	16 B	Gray	Top Entry	125 °C	-40 C	IP65 - Dust Tight Water Resistant			PG21
HARTING 09300161230	Base - Box Mount		4.606 in	2.197 in		117 mm	2.244 "	Powder Coated	Locking Clip (2) on Base Bottom	Aluminum Die Cast	16 B	Gray	Side Entry	125 °C	-40 C	IP65 - Dust Tight Water Resistant	57 mm	55.8 mm	PG21
HARTING 09300161295	Base - Box Mount		4.606 in	2.197 in		117 mm	2.244 "	Powder Coated	Locking Clip (1) on Base Bottom	Aluminum Die Cast	16 B	Gray	Side Entry	125 °C	-40 C	IP65 - Dust Tight Water Resistant	57 mm	55.8 mm	PG21
