HDSP-A22 Series
Manufacturer: Broadcom Limited
Beta
⌘K
DISPLAY 7SEG 0.54" DBL GRN 18DIP
| Part | Common Pin | Wavelength - Peak | Display Type | Digit/Alpha Size [custom] | Digit/Alpha Size | Millicandela Rating | Current - Test | Color | Voltage - Forward (Vf) (Typ) | Power Dissipation (Max) [Max] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [x] | Number of Characters | Package / Case [x] | Package / Case [x] | Package / Case | Digit/Alpha Size | Millicandela Rating [Max] | Millicandela Rating [Min] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Broadcom Limited | Common Anode | 568 nm | 7-Segment | 0.54 in | 13.8 mm | 5 mcd | 20 mA | Green | 2.25 V | 52 mW | 21 mm | 1 " | 0.3 " | 0.8 " | 25 mm | 7 mm | 2 | 15.24 mm | 0.6 in | 18-DIP | |||
 Broadcom Limited | Common Anode | 635 nm | 14-Segment Alphanumeric | 13.72 mm | 20 mA | Red | 1.9 V | 0.827 in 21 mm | 0.992 " 25.2 mm | 0.276 " 7 mm | 2 | 15.24 mm | 0.6 in | 18-DIP | 0.54 " | 36 mcd | 18 mcd |
