AE320F Series
Manufacturer: Conesys
Beta
⌘K
CONN RCPT HSG FMALE 79POS PNL MT
| Part | Shell Material | Operating Temperature [Min] | Operating Temperature [Max] | Shell Size - Insert | Connector Type | Type | Shell Finish | Shielding | Number of Positions | Mounting Feature | Qualification | Fastening Type | Contact Type | Orientation | Mounting Type | Contact Size | Note | Termination | Current Rating (Amps) | Contact Finish - Mating | Primary Material | Contact Size | Contact Size [custom] | Contact Size [custom] | Number of Positions [custom] | Number of Positions [custom] | Number of Positions [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Conesys | Aluminum | -65 ░C | 200 °C | G-35 | Receptacle Housing | For Female Sockets | Nickel | Shielded | 79 | Flange | MIL-DTL-38999 Series III | Threaded | Crimp | A | Panel Mount | 22D | Contacts Not Included | ||||||||||
Conesys | Aluminum | -65 ░C | 200 °C | B-2 | Receptacle Female Sockets | Nickel | Shielded | 2 | Flange | Threaded | N (Normal) | Panel Mount | Crimp | 13 A | Gold | Metal | |||||||||||
Conesys | Aluminum | -65 ░C | 200 °C | J8 | Receptacle Female Sockets | Nickel | Shielded | 8 | Flange | Threaded | N (Normal) | Panel Mount | Crimp | 45 A | Gold | Metal | |||||||||||
Conesys | Aluminum | -65 ░C | 200 °C | C-4 | Receptacle Housing | For Female Sockets | Nickel | Shielded | 4 | Flange | MIL-DTL-38999 Series III | Threaded | Crimp | N (Normal) | Panel Mount | Contacts Not Included | 16 | ||||||||||
Conesys | Aluminum | -65 ░C | 200 °C | A-98 | Receptacle Housing | For Female Sockets | Nickel | Shielded | Flange | MIL-DTL-38999 Series III | Threaded | Crimp | N (Normal) | Panel Mount | Contacts Not Included | 20 | |||||||||||
Conesys | Aluminum | -65 ░C | 200 °C | C-35 | Receptacle Male Pins | Nickel | Shielded | 22 | Flange | Threaded | N (Normal) | Panel Mount | Crimp | Metal | |||||||||||||
Conesys | Aluminum | -65 ░C | 200 °C | J-20 | Receptacle Housing | For Female Sockets | Nickel | Shielded | Flange | MIL-DTL-38999 Series III | Threaded | Crimp | N (Normal) | Panel Mount | Contacts Not Included | 4 10 13 | 12 16 20 | 23 | 4 | 3 | |||||||
 Conesys | Aluminum | -65 ░C | 200 °C | C-35 | Receptacle Female Sockets | Nickel | Shielded | 22 | Flange | Threaded | N (Normal) | Panel Mount | Crimp | 5 A | Gold | Metal | |||||||||||
Conesys | Aluminum | -65 ░C | 200 °C | J4 | Receptacle Male Pins | Nickel | Shielded | 56 | Flange | Threaded | N (Normal) | Panel Mount | Crimp | 7.5 A 13 A | Gold | Metal | |||||||||||
Conesys | Aluminum | -65 ░C | 200 °C | G-16 | Receptacle Male Pins | Nickel | Shielded | 16 | Flange | Threaded | N (Normal) | Panel Mount | Crimp | Metal |
