1089A Series
Manufacturer: Belden Inc.
Beta
⌘K
MULTI-PAIR 72COND 16AWG
| Part | Shield Coverage | Shield Material | Shield Type | Jacket (Insulation) Material | Conductor Strand [custom] | Conductor Strand [custom] | Jacket (Insulation) Thickness [custom] | Jacket (Insulation) Thickness [custom] | Conductor Material | Length | Length | Jacket Color | Number of Conductors | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Features | Conductor Insulation | Conductor Insulation | Conductor Insulation | Cable Type | Wire Gauge |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Belden Inc. | 100 % | Aluminum | Foil | Poly-Vinyl Chloride (PVC) | 7 | 24 AWG | 2.134 mm | 0.084 " | Copper Bare | 381 m | 1250 ft | Black | 72 | 32.94 mm | 1.297 " | Drain Wire Rip Cord | Polyamide (PA) | Nylon | Poly-Vinyl Chloride (PVC) | Multi-Pair | 16 AWG |
 Belden Inc. | 100 % | Aluminum | Foil | Poly-Vinyl Chloride (PVC) | 7 | 24 AWG | 2.134 mm | 0.084 " | Copper Bare | 762 m | 2500 ft | Black | 72 | 32.94 mm | 1.297 " | Drain Wire Rip Cord | Polyamide (PA) | Nylon | Poly-Vinyl Chloride (PVC) | Multi-Pair | 16 AWG |
 Belden Inc. | 100 % | Aluminum | Foil | Poly-Vinyl Chloride (PVC) | 7 | 24 AWG | 2.134 mm | 0.084 " | Copper Bare | Black | 72 | 32.94 mm | 1.297 " | Drain Wire Rip Cord | Polyamide (PA) | Nylon | Poly-Vinyl Chloride (PVC) | Multi-Pair | 16 AWG |
