395-041 Series
Manufacturer: EDAC Inc.
Beta
⌘K
.100" (2.54MM) PITCH CARD EDGE CONNECTOR ROHS COMPLIANT: YES
| Part | Material - Insulation | Termination Rows | Contact Type | Mounting Type | Number of Rows | Pitch | Pitch | Contact Finish Thickness | Contact Finish Thickness | Number of Positions/Bay/Row | Operating Temperature [Min] | Operating Temperature [Max] | Card Thickness [Max] | Card Thickness [Min] | Contact Finish | Gender | Contact Material | Termination | Color | Card Type | Number of Positions | Read Out | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 1 | Cantilever | Through Hole | 1 | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | 41 | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Female | Copper Alloy | Solder | Black | Non Specified - Single Edge | 41 | Single | ||||
 EDAC Inc. | Polyester Thermoplastic | 1 | Cantilever | Through Hole | 1 | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | 41 | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Female | Copper Alloy | Wire Wrap | Black | Non Specified - Single Edge | 41 | Single | 4-40 Threaded Insert Top Mount Opening | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | Cantilever | Through Hole | 1 | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | 41 | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Female | Copper Alloy | Solder | Black | Non Specified - Single Edge | 41 | Single | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | |
 EDAC Inc. | Polyester Thermoplastic | 1 | Cantilever | Through Hole | 1 | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | 41 | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Female | Copper Alloy | Solder | Black | Non Specified - Single Edge | 41 | Single | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | |
 EDAC Inc. | Polyester Thermoplastic | 1 | Cantilever | Through Hole | 1 | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | 41 | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Female | Copper Alloy | Wire Wrap | Black | Non Specified - Single Edge | 41 | Single | 0.156 " | 3.96 mm | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | Cantilever | Through Hole | 1 | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | 41 | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Female | Copper Alloy | Wire Wrap | Black | Non Specified - Single Edge | 41 | Single | 4-40 Threaded Insert Top Mount Opening | Card Guides | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | Cantilever | Through Hole | 1 | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | 41 | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Female | Copper Alloy | Solder | Black | Non Specified - Single Edge | 41 | Single | 4-40 Flush Mount Threaded Insert Top Opening | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | Cantilever | Through Hole | 1 | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | 41 | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Female | Copper Alloy | Wire Wrap | Black | Non Specified - Single Edge | 41 | Single | 4-40 Threaded Insert Top Mount Opening | Card Guides | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | Cantilever | Through Hole | 1 | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | 41 | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Female | Copper Alloy | Solder | Black | Non Specified - Single Edge | 41 | Single | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | |
 EDAC Inc. | Polyester Thermoplastic | 1 | Cantilever | Through Hole | 1 | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | 41 | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Female | Copper Alloy | Wire Wrap | Black | Non Specified - Single Edge | 41 | Single | 4-40 Threaded Insert Top Mount Opening |
