3118-1 Series

Catalog

CONN PC PIN CIRC

Part	Board Thickness	Board Thickness	Termination	Insulation	Terminal Style	Length - Below Flange [x]	Length - Below Flange [x]	Contact Finish	Terminal Type	Contact Finish Thickness	Contact Finish Thickness	Contact Material	Length - Overall [x]	Length - Overall [x]	Mounting Hole Diameter [diameter]	Mounting Hole Diameter [diameter]	Length - Above Flange	Length - Above Flange [x]	Mounting Type	Pin Size - Above Flange [diameter]	Pin Size - Above Flange [diameter]	Flange Diameter	Flange Diameter
Mill-Max Manufacturing Corp. 3118-1-00-80-00-00-08-0	0.79 mm	0.031 in	Swage	Non-Insulated	Single End	0.051 "	1.3 mm	Tin	PC Pin	200 Áin	5.08 Ám	Brass Alloy	0.371 in	9.42 mm	0.89 mm	0.035 in	3.81 mm	0.15 in	Through Hole	0.64 mm	0.025 in	0.05 in	1.27 mm
Mill-Max Manufacturing Corp. 3118-1-00-21-00-00-08-0	0.79 mm	0.031 in	Swage	Non-Insulated	Single End	0.051 "	1.3 mm	Gold	PC Pin	20 µin	0.51 µm	Brass Alloy	0.371 in	9.42 mm	0.89 mm	0.035 in	3.81 mm	0.15 in	Through Hole	0.64 mm	0.025 in	0.05 in	1.27 mm
Mill-Max Manufacturing Corp. 3118-1-00-01-00-00-08-0	0.79 mm	0.031 in	Swage	Non-Insulated	Single End	0.051 "	1.3 mm	Tin-Lead	PC Pin	200 Áin	5.08 Ám	Brass Alloy	0.371 in	9.42 mm	0.89 mm	0.035 in	3.81 mm	0.15 in	Through Hole	0.64 mm	0.025 in	0.05 in	1.27 mm
Mill-Max Manufacturing Corp. 3118-1-00-15-00-00-08-0	0.79 mm	0.031 in	Swage	Non-Insulated	Single End	0.051 "	1.3 mm	Gold	PC Pin	10 Áin	0.25 Ám	Brass Alloy	0.371 in	9.42 mm	0.89 mm	0.035 in	3.81 mm	0.15 in	Through Hole	0.64 mm	0.025 in	0.05 in	1.27 mm
