ECW-F2564 Series

Catalog

CAP FILM 0.56UF 3% 250VDC RADIAL

Part	Package / Case	Capacitance	Lead Spacing	Lead Spacing	Dielectric Material	Operating Temperature [Min]	Operating Temperature [Max]	Termination	Voltage Rating - DC	Applications	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Mounting Type	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Tolerance	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Voltage Rating - AC
Panasonic Electronic Components ECW-F2564HAB	Radial	560 nF	0.295 in	7.5 mm	Polypropylene (PP) Metallized	-40 C	105 ░C	PC Pins	250 V	High Frequency Switching	0.705 "	17.9 mm	Through Hole	6.9 mm	0.713 "	18.1 mm	0.272 in	3 %
Panasonic Electronic Components ECW-F2564HAQ	Radial	560 nF	0.591 in	15 mm	Polypropylene (PP) Metallized	-40 C	105 ░C	PC Pins	250 V	High Frequency Switching			Through Hole	6.9 mm	0.713 "	18.1 mm	0.272 in	3 %	0.783 "	19.9 mm
Panasonic Electronic Components ECW-F2564RJA	Radial	560 nF	0.295 in	7.5 mm	Polypropylene (PP) Metallized	-40 C	105 ░C	PC Pins	250 V	High Frequency Switching			Through Hole	6.9 mm	0.713 "	18.1 mm	0.272 in	5 %
Panasonic Electronic Components ECW-F2564JAQ	Radial	560 nF	0.591 in	15 mm	Polypropylene (PP) Metallized	-40 C	105 ░C	PC Pins	250 V	High Frequency Switching			Through Hole	6.9 mm	0.713 "	18.1 mm	0.272 in	5 %	0.783 "	19.9 mm	125 V
