HCPL-M453 Series

Catalog

OPTOISO 3.75KV TRANSISTOR 6SOIC

Part	Voltage - Isolation	Voltage - Output (Max) [Max]	Current Transfer Ratio (Min)	Mounting Type	Operating Temperature [Max]	Operating Temperature [Min]	Current - DC Forward (If) (Max) [Max]	Number of Channels [custom]	Turn On / Turn Off Time (Typ) [custom]	Turn On / Turn Off Time (Typ) [custom]	Current Transfer Ratio (Max)	Package / Case	Package / Case	Voltage - Forward (Vf) (Typ)	Input Type	Output Type	Current - Output / Channel	Supplier Device Package
Broadcom Limited HCPL-M453#500	3750 Vrms	20 V	20 %	Surface Mount	100 °C	-55 C	25 mA	1	200 ns	600 ns	50 %	6-SOIC	0.173 " 4.4 mm Width 5 Leads	1.5 V	DC	Transistor	8 mA
Broadcom Limited HCPL-M453-000E	3750 Vrms	20 V	20 %	Surface Mount	100 °C	-55 C	25 mA	1	200 ns	600 ns	50 %	6-SOIC	0.173 " 4.4 mm Width 5 Leads	1.5 V	DC	Transistor	8 mA	6-SO
Broadcom Limited HCPL-M453	3750 Vrms	20 V	20 %	Surface Mount	100 °C	-55 C	25 mA	1	200 ns	600 ns	50 %	6-SOIC	0.173 " 4.4 mm Width 5 Leads	1.5 V	DC	Transistor	8 mA
