895-069 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 69POS 0.100
| Part | Termination | Operating Temperature [Max] | Operating Temperature [Min] | Number of Positions | Termination Rows | Read Out | Color | Mounting Type | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Number of Positions/Bay/Row [custom] | Contact Finish | Gender | Material - Insulation | Contact Material | Contact Type | Pitch | Pitch | Number of Rows | Contact Finish Thickness | Contact Finish Thickness | Card Thickness [Max] | Card Thickness [Min] | Card Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Solder | 125 °C | -40 C | 69 | 1 | Single | Black | Through Hole | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | 69 | Gold | Female | Polyphenylene Sulfide (PPS) | Copper Alloy | Cantilever | 0.1 " | 2.54 mm | 1 | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge |
 EDAC Inc. | Solder | 125 °C | -40 C | 69 | 1 | Single | Black | Right Angle Through Hole | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | 69 | Gold | Female | Polyphenylene Sulfide (PPS) | Copper Alloy | Cantilever | 0.1 " | 2.54 mm | 1 | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge |
 EDAC Inc. | Solder | 125 °C | -40 C | 69 | 1 | Single | Black | Through Hole | 4-40 Threaded Insert Top Mount Opening | 69 | Gold | Female | Polyphenylene Sulfide (PPS) | Copper Alloy | Cantilever | 0.1 " | 2.54 mm | 1 | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | ||
 EDAC Inc. | Solder Eyelet(s) | 125 °C | -40 C | 69 | 1 | Single | Black | Through Hole | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | 69 | Gold | Female | Polyphenylene Sulfide (PPS) | Copper Alloy | Cantilever | 0.1 " | 2.54 mm | 1 | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge |
 EDAC Inc. | Wire Wrap | 125 °C | -40 C | 69 | 1 | Single | Black | Through Hole | Flush Mount M3 Threaded Insert Top Opening | 69 | Gold | Female | Polyphenylene Sulfide (PPS) | Copper Alloy | Cantilever | 0.1 " | 2.54 mm | 1 | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | ||
 EDAC Inc. | Solder Eyelet(s) | 125 °C | -40 C | 69 | 1 | Single | Black | Through Hole | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | 69 | Gold | Female | Polyphenylene Sulfide (PPS) | Copper Alloy | Cantilever | 0.1 " | 2.54 mm | 1 | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge |
 EDAC Inc. | Solder | 125 °C | -40 C | 69 | 1 | Single | Black | Through Hole | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | 69 | Gold | Female | Polyphenylene Sulfide (PPS) | Copper Alloy | Cantilever | 0.1 " | 2.54 mm | 1 | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge |
 EDAC Inc. | Solder | 125 °C | -40 C | 69 | 1 | Single | Black | Right Angle Through Hole | Flush Mount M3 Threaded Insert Top Opening | 69 | Gold | Female | Polyphenylene Sulfide (PPS) | Copper Alloy | Cantilever | 0.1 " | 2.54 mm | 1 | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | ||
 EDAC Inc. | Solder | 125 °C | -40 C | 69 | 1 | Single | Black | Through Hole | 4-40 Threaded Insert Top Mount Opening | 69 | Gold | Female | Polyphenylene Sulfide (PPS) | Copper Alloy | Cantilever | 0.1 " | 2.54 mm | 1 | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | ||
 EDAC Inc. | Solder | 125 °C | -40 C | 69 | 1 | Single | Black | Through Hole | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | 69 | Gold | Female | Polyphenylene Sulfide (PPS) | Copper Alloy | Cantilever | 0.1 " | 2.54 mm | 1 | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge |
