FWG.0B Series
Manufacturer: LEMO
Beta
⌘K
CONN PLUG MALE 5P GOLD SLDR CUP
| Part | Backshell Material, Plating | Contact Finish Thickness - Mating [custom] | Contact Finish Thickness - Mating [custom] | Current Rating (Amps) | Color | Number of Positions | Orientation [custom] | Shell Finish | Material Flammability Rating | Shell Size - Insert | Shielding | Contact Finish - Mating | Operating Temperature [Min] | Operating Temperature [Max] | Shell Material | Mounting Feature | Contact Material | Connector Type | Insert Material | Fastening Type | Mounting Type | Ingress Protection | Primary Material | Termination |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 LEMO | Brass Chrome | 39.4 µin | 1 µm | 6.5 A | Silver | 5 | G | Chrome | UL94 V-0 | 305 | Shielded | Gold | -55 C | 250 °C | Brass | Bulkhead - Rear Side Nut | Brass | Plug Male Pins | Polyetheretherketone (PEEK) | Push-Pull | Panel Mount | IP50 - Dust Protected | Metal | |
LEMO | Brass Chrome | 39.4 µin | 1 µm | 2 A | Silver | 9 | G | Chrome | UL94 V-0 | 309 | Shielded | Gold | -55 C | 250 °C | Brass | Bulkhead - Rear Side Nut | Brass | Plug Male Pins | Polyetheretherketone (PEEK) | Push-Pull | Panel Mount | IP50 - Dust Protected | Metal | |
LEMO | Brass Chrome | 39.4 µin | 1 µm | 7 A | Silver | 4 | G | Chrome | UL94 V-0 | 304 | Shielded | Gold | -55 C | 250 °C | Brass | Bulkhead - Rear Side Nut | Brass | Plug Male Pins | Polyetheretherketone (PEEK) | Push-Pull | Panel Mount | IP50 - Dust Protected | Metal | Crimp |
