F221V3/4 Series

Catalog

FIT221V3/4 BLUE 250 FT ROHS COMPLIANT: YES

Part	Shelf Life Start	Material	Operating Temperature [Min]	Operating Temperature [Max]	Inner Diameter - Recovered [diameter]	Inner Diameter - Recovered [diameter]	Features	Recovered Wall Thickness	Recovered Wall Thickness	Shelf Life	Shrink Temperature	Length	Length	Shrinkage Ratio [Min]	Shrinkage Ratio [Max]	Color	Type	Length [x]	Length [x]
ALPHA WIRE F221V3/4 BL003	Date of Manufacture	Polyolefin (PO) Irradiated	-55 C	135 °C	9.53 mm	0.375 in	Flame Retardant Fluid Resistant Heat Resistant	0.76 mm	0.03 in	144 Months	90 °C	76.2 m	250 ft	1	2	Blue	Tubing Flexible
ALPHA WIRE F221V3/4 GR105	Date of Manufacture	Polyolefin (PO) Irradiated	-55 C	135 °C	9.53 mm	0.375 in	Flame Retardant Fluid Resistant Heat Resistant	0.76 mm	0.03 in	144 Months	90 °C			1	2	Green	Tubing Flexible	4 ft	1.22 m
ALPHA WIRE F221V3/4 GR003	Date of Manufacture	Polyolefin (PO) Irradiated	-55 C	135 °C	9.53 mm	0.375 in	Flame Retardant Fluid Resistant Heat Resistant	0.76 mm	0.03 in	144 Months	90 °C	76.2 m	250 ft	1	2	Green	Tubing Flexible
ALPHA WIRE F221V3/4 RD003	Date of Manufacture	Polyolefin (PO) Irradiated	-55 C	135 °C	9.53 mm	0.375 in	Flame Retardant Fluid Resistant Heat Resistant	0.76 mm	0.03 in	144 Months	90 °C	76.2 m	250 ft	1	2	Red	Tubing Flexible
ALPHA WIRE F221V3/4 WH003	Date of Manufacture	Polyolefin (PO) Irradiated	-55 C	135 °C	9.53 mm	0.375 in	Flame Retardant Fluid Resistant Heat Resistant	0.76 mm	0.03 in	144 Months	90 °C	76.2 m	250 ft	1	2	White	Tubing Flexible
