LHS-08 Series
Manufacturer: Adam Tech
Beta
⌘K
CONN HEADER VERT 8POS 2.54MM
| Part | Contact Length - Post [x] | Contact Length - Post | Connector Type | Fastening Type | Insulation Color | Mounting Type | Insulation Height [z] | Insulation Height | Style | Material Flammability Rating | Overall Contact Length | Overall Contact Length | Contact Shape | Number of Positions | Number of Rows | Number of Positions Loaded | Contact Material | Shrouding | Contact Type | Voltage Rating | Current Rating (Amps) | Contact Finish - Post | Operating Temperature [Max] | Operating Temperature [Min] | Insulation Material | Termination | Pitch - Mating | Pitch - Mating | Contact Length - Mating [custom] | Contact Length - Mating [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Adam Tech | 0.134 " | 3.4 mm | Header | Friction Lock | White | Through Hole | 0.327 " | 8.3 mm | Board to Cable/Wire | UL94 V-0 | 14.2 mm | 0.559 " | Square | 8 | 1 | All | Brass | Shrouded - 1 Wall | Male Pin | 250 VAC | 3 A | Tin | 85 °C | -25 °C | Nylon 6/6 Polyamide (PA66) | Solder | 0.1 " | 2.54 mm | 7.6 mm | 0.299 in |
