307-025 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 25POS 0.156
| Part | Material - Insulation | Termination Rows | Contact Finish Thickness | Contact Finish Thickness | Color | Contact Material | Mounting Type | Number of Rows | Read Out | Pitch | Pitch | Termination | Contact Type | Card Thickness [Max] | Card Thickness [Min] | Operating Temperature [Min] | Operating Temperature [Max] | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Contact Finish | Number of Positions | Gender | Number of Positions/Bay/Row | Card Type | Features | Number of Rows [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 1 | 0.25 Ám | 10 Áin | Green | Copper Alloy | Through Hole | 1 | Single | 3.96 mm | 0.156 in | Wire Wrap | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | Gold | 25 | Female | 25 | Non Specified - Single Edge | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | Green | Copper Alloy | Right Angle Through Hole | 1 | Single | 3.96 mm | 0.156 in | Solder | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | 4-40 Flush Mount Threaded Insert Top Opening | Tin | 25 | Female | 25 | Non Specified - Single Edge | Card Guides | |||||
 EDAC Inc. | Polyester Thermoplastic | 1 | 0.25 Ám | 10 Áin | Green | Copper Alloy | Right Angle Through Hole | Dual | 3.96 mm | 0.156 in | Wire Wrap | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | Gold | 50 | Female | 25 | Non Specified - Dual Edge | 2 | |||||
 EDAC Inc. | Polyester Thermoplastic | 1 | Green | Copper Alloy | Right Angle Through Hole | 1 | Single | 3.96 mm | 0.156 in | Solder | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | Tin | 25 | Female | 25 | Non Specified - Single Edge | |||||||
 EDAC Inc. | Polyester Thermoplastic | 1 | 0.25 Ám | 10 Áin | Green | Copper Alloy | Through Hole | 1 | Single | 3.96 mm | 0.156 in | Solder | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | Gold | 25 | Female | 25 | Non Specified - Single Edge | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | 0.25 Ám | 10 Áin | Green | Copper Alloy | Right Angle Through Hole | Dual | 3.96 mm | 0.156 in | Wire Wrap | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | Gold | 50 | Female | 25 | Non Specified - Dual Edge | 2 | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | Green | Copper Alloy | Right Angle Through Hole | 1 | Single | 3.96 mm | 0.156 in | Solder | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | 4-40 Flush Mount Threaded Insert Top Opening | Tin | 25 | Female | 25 | Non Specified - Single Edge | Card Guides | |||||
 EDAC Inc. | Polyester Thermoplastic | 1 | 0.25 Ám | 10 Áin | Green | Copper Alloy | Surface Mount | Dual | 3.96 mm | 0.156 in | Solder Eyelet(s) | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | Flush Mount Side Opening Unthreaded | 3.25 mm | 0.128 " | Gold | 50 | Female | 25 | Non Specified - Dual Edge | 2 | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | 0.25 Ám | 10 Áin | Green | Copper Alloy | Through Hole | 1 | Single | 3.96 mm | 0.156 in | Solder | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | Gold | 25 | Female | 25 | Non Specified - Single Edge | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | 0.25 Ám | 10 Áin | Green | Copper Alloy | Right Angle Through Hole | Dual | 3.96 mm | 0.156 in | Wire Wrap | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | Flush Mount Side Opening Unthreaded | 3.25 mm | 0.128 " | Gold | 50 | Female | 25 | Non Specified - Dual Edge | 2 |
