IL-G-4P Series
Manufacturer: JAE Electronics
Beta
⌘K
CONN HEADER VERT 4POS 2.5MM
| Part | Mated Stacking Heights | Pitch - Mating | Pitch - Mating | Contact Shape | Fastening Type | Insulation Material | Overall Contact Length | Overall Contact Length | Contact Material | Number of Positions Loaded | Insulation Color | Contact Length - Mating | Contact Length - Mating | Current Rating (Amps) | Style | Contact Type | Material Flammability Rating | Shrouding | Number of Rows | Contact Finish - Mating | Contact Length - Post | Contact Length - Post | Termination | Connector Type | Operating Temperature [Max] | Operating Temperature [Min] | Contact Finish - Post | Insulation Height | Insulation Height | Number of Positions | Mounting Type | Insulation Height [custom] | Insulation Height [custom] | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 JAE Electronics | 10 mm | 2.5 mm | 0.098 in | Square | Friction Lock | Nylon 6/6 Polyamide (PA66) | 9.6 mm | 0.378 in | Brass | All | Brown | 4 mm | 0.157 in | 3 A | Board to Cable/Wire | Male Pin | UL94 V-0 | Shrouded - 1 Wall | 1 | Gold | 0.138 in | 3.5 mm | Solder | Header | 85 °C | -40 C | Gold | 0.28 in | 7.1 mm | 4 | Through Hole | ||||
 JAE Electronics | 2.5 mm | 0.098 in | Square | Friction Lock | Nylon 6/6 Polyamide (PA66) | Brass | All | Brown | 4 mm | 0.157 in | 3 A | Board to Cable/Wire | Male Pin | UL94 V-0 | Shrouded - 1 Wall | 1 | 0.138 in | 3.5 mm | Solder | Header | 85 °C | -40 C | Tin | 4 | Right Angle Through Hole | 0.236 " | 6 mm | ||||||||
 JAE Electronics | 10 mm | 2.5 mm | 0.098 in | Square | Friction Lock | Nylon 6/6 Polyamide (PA66) | 9.6 mm | 0.378 in | Brass | All | Brown | 4 mm | 0.157 in | 3 A | Board to Cable/Wire | Male Pin | UL94 V-0 | Shrouded - 1 Wall | 1 | 0.138 in | 3.5 mm | Solder | Header | 85 °C | -40 C | Tin | 0.28 in | 7.1 mm | 4 | Through Hole | |||||
 JAE Electronics | 2.5 mm | 0.098 in | Square | Friction Lock | Nylon 6/6 Polyamide (PA66) | Brass | 3 A | Board to Cable/Wire | UL94 V-0 | Shrouded - 1 Wall | 1 | Header | 85 °C | -40 C | 4 | Right Angle Through Hole | |||||||||||||||||||
JAE Electronics | 2.5 mm | 0.098 in | Square | Friction Lock | Nylon 6/6 Polyamide (PA66) | Brass | All | Brown | 4 mm | 0.157 in | 3 A | Board to Cable/Wire | Male Pin | UL94 V-0 | Shrouded - 1 Wall | 1 | Gold | 0.138 in | 3.5 mm | Solder | Header | 85 °C | -40 C | 4 | Right Angle Through Hole | 0.236 " | 6 mm | 3.9 µin | 0.099 µm |
