1445097 Series

Manufacturer: TE Connectivity AMP Connectors

Catalog

CONN HEADER R/A 8POS 3MM

Part	Applications	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Insulation Material	Pitch - Mating	Pitch - Mating	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Insulation Color	Contact Length - Post [x]	Contact Length - Post [x]	Connector Type	Contact Type	Termination	Contact Finish - Post	Number of Positions	Style	Voltage Rating	Features	Contact Finish - Mating	Number of Positions Loaded	Contact Material	Insulation Height [custom]	Insulation Height [custom]	Number of Rows	Contact Shape	Current Rating (Amps)	Material Flammability Rating	Shrouding	Fastening Type	Mounting Type	Operating Temperature [Min]	Operating Temperature [Max]
TE Connectivity AMP Connectors 1445097-8	General Purpose	2.54 µm	100 µin	Nylon Polyamide (PA)	3 mm	0.118 in	0.76 Ám	30 Áin	Black	0.114 in	2.9 mm	Header	Male Pin	Solder	Tin-Lead	8	Board to Cable/Wire	250 V	Board Lock	Gold	All	Brass	0.152 in	3.85 mm	1	Square	Varies by Wire Gauge	UL94 V-0	Shrouded - 4 Wall	Locking Ramp	Right Angle Through Hole	-40 C	105 ░C
TE Connectivity AMP Connectors 3-1445097-0	General Purpose	2.54 µm	100 µin	Nylon Polyamide (PA)	3 mm	0.118 in	0.76 Ám	30 Áin	Black	0.114 in	2.9 mm	Header	Male Pin	Solder	Tin	10	Board to Cable/Wire	250 V	Board Lock	Gold	All	Brass	0.152 in	3.85 mm	1	Square	Varies by Wire Gauge	UL94 V-0	Shrouded - 4 Wall	Locking Ramp	Right Angle Through Hole	-40 C	105 ░C
TE Connectivity AMP Connectors 2-1445097-9	General Purpose	2.54 µm	100 µin	Nylon Polyamide (PA)	3 mm	0.118 in	0.76 Ám	30 Áin	Black	0.114 in	2.9 mm	Header	Male Pin	Solder	Tin	9	Board to Cable/Wire	250 V	Board Lock	Gold	All	Brass	0.152 in	3.85 mm	1	Square	Varies by Wire Gauge	UL94 V-0	Shrouded - 4 Wall	Locking Ramp	Right Angle Through Hole	-40 C	105 ░C
TE Connectivity AMP Connectors 1445097-7	General Purpose	2.54 µm	100 µin	Nylon Polyamide (PA)	3 mm	0.118 in	0.76 Ám	30 Áin	Black	0.114 in	2.9 mm	Header	Male Pin	Solder	Tin-Lead	7	Board to Cable/Wire	250 V	Board Lock	Gold	All	Brass	0.152 in	3.85 mm	1	Square	Varies by Wire Gauge	UL94 V-0	Shrouded - 4 Wall	Locking Ramp	Right Angle Through Hole	-40 C	105 ░C
