315-022 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 22POS 0.156
| Part | Termination Rows [custom] | Material - Insulation | Contact Type | Contact Finish Thickness | Contact Finish Thickness | Termination | Gender | Color | Contact Material | Contact Finish | Pitch | Pitch | Flange Feature [diameter] | Flange Feature | Flange Feature [diameter] | Operating Temperature [Min] | Operating Temperature [Max] | Number of Positions | Number of Rows [custom] | Read Out | Number of Positions/Bay/Row | Card Type | Mounting Type | Card Thickness [Max] | Card Thickness [Min] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Polyester Thermoplastic | Semi Bellows | 0.25 Ám | 10 Áin | Solder | Female | Green | Copper Alloy | Gold | 3.96 mm | 0.156 in | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | -40 C | 105 ░C | 22 | 2 | Dual | 11 | Non Specified - Dual Edge | Panel Mount Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | |
 EDAC Inc. | 2 | Polyester Thermoplastic | Semi Bellows | 0.25 Ám | 10 Áin | Solder Eyelet(s) | Female | Green | Copper Alloy | Gold | 3.96 mm | 0.156 in | 4-40 Flush Mount Threaded Insert Top Opening | -40 C | 105 ░C | 22 | 2 | Dual | 11 | Non Specified - Dual Edge | Panel Mount | 0.07 in 1.78 mm | 0.054 in 1.37 mm | |||
 EDAC Inc. | 2 | Polyester Thermoplastic | Semi Bellows | 0.25 Ám | 10 Áin | Solder | Female | Green | Copper Alloy | Gold | 3.96 mm | 0.156 in | 0.128 " | Flush Mount Top Opening Unthreaded | 3.25 mm | -40 C | 105 ░C | 22 | 2 | Dual | 11 | Non Specified - Dual Edge | Panel Mount Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | |
 EDAC Inc. | 2 | Polyester Thermoplastic | Semi Bellows | 0.25 Ám | 10 Áin | Solder | Female | Green | Copper Alloy | Gold | 3.96 mm | 0.156 in | -40 C | 105 ░C | 22 | 2 | Dual | 11 | Non Specified - Dual Edge | Board Edge Straddle Mount | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Card Extender | |||
 EDAC Inc. | 2 | Polyester Thermoplastic | Semi Bellows | 0.25 Ám | 10 Áin | Solder | Female | Green | Copper Alloy | Gold | 3.96 mm | 0.156 in | 4-40 Flush Mount Threaded Insert Top Opening | -40 C | 105 ░C | 22 | 2 | Dual | 11 | Non Specified - Dual Edge | Board Edge Straddle Mount | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Card Extender Card Guides | ||
 EDAC Inc. | 2 | Polyester Thermoplastic | Semi Bellows | 0.25 Ám | 10 Áin | Solder | Female | Green | Copper Alloy | Gold | 3.96 mm | 0.156 in | 0.156 " | Flush Mount Top Opening Unthreaded | 3.96 mm | -40 C | 105 ░C | 22 | 2 | Dual | 11 | Non Specified - Dual Edge | Panel Mount Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | |
 EDAC Inc. | 2 | Polyester Thermoplastic | Semi Bellows | 0.25 Ám | 10 Áin | Solder | Female | Green | Copper Alloy | Gold | 3.96 mm | 0.156 in | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | -40 C | 105 ░C | 22 | 2 | Dual | 11 | Non Specified - Dual Edge | Board Edge Straddle Mount | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Card Extender |
 EDAC Inc. | 2 | Polyester Thermoplastic | Semi Bellows | 0.25 Ám | 10 Áin | Solder | Female | Green | Copper Alloy | Gold | 3.96 mm | 0.156 in | 0.156 " | Flush Mount Top Opening Unthreaded | 3.96 mm | -40 C | 105 ░C | 22 | 2 | Dual | 11 | Non Specified - Dual Edge | Board Edge Straddle Mount | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Card Extender |
 EDAC Inc. | 2 | Polyester Thermoplastic | Semi Bellows | 0.25 Ám | 10 Áin | Solder | Female | Green | Copper Alloy | Gold | 3.96 mm | 0.156 in | 0.128 " | Flush Mount Top Opening Unthreaded | 3.25 mm | -40 C | 105 ░C | 22 | 2 | Dual | 11 | Non Specified - Dual Edge | Board Edge Straddle Mount | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Card Extender |
 EDAC Inc. | 2 | Polyester Thermoplastic | Semi Bellows | 0.25 Ám | 10 Áin | Solder | Female | Green | Copper Alloy | Gold | 3.96 mm | 0.156 in | Flush Mount M3 Threaded Insert Top Opening | -40 C | 105 ░C | 22 | 2 | Dual | 11 | Non Specified - Dual Edge | Panel Mount Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm |
