622-009 Series
Manufacturer: EDAC Inc.
Beta
⌘K
EDAC STANDARD RIGHT ANGLE D-SUB CONNECTOR ROHS COMPLIANT: YES
| Part | Color | Operating Temperature [Min] | Operating Temperature [Max] | Dielectric Material | Contact Material | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout [custom] | Current Rating (Amps) | Flange Feature | Backset Spacing | Backset Spacing | Number of Rows [custom] | Contact Finish | Shell Material, Finish | Number of Positions | Material Flammability Rating | Connector Type | Mounting Type | Contact Finish Thickness | Contact Finish Thickness | Contact Type | Connector Style | Features | Termination | Flange Feature | Contact Finish Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Black | -55 C | 85 °C | Polyester Thermoplastic | Copper Alloy | 1 | DE E | 3 A | Housing/Shell (Unthreaded) | 8.08 mm | 0.318 " | 2 | Gold | Nickel Plated Steel | 9 | UL94 V-0 | Receptacle Female Sockets | Board Edge Right Angle Through Hole | 0.38 µm | 15 µin | Signal | D-Sub | Filter Mounting Brackets Shielded | Solder | ||
 EDAC Inc. | Black | -55 C | 85 °C | Polyester Thermoplastic | Copper Alloy | 1 | DE E | 3 A | Housing/Shell | 8.08 mm | 0.318 " | 2 | Gold | Nickel Plated Steel | 9 | UL94 V-0 | Receptacle Female Sockets | Board Edge Right Angle Through Hole | Signal | D-Sub | Mounting Brackets Shielded | Solder | 4-40 | Flash | ||
 EDAC Inc. | Black | -55 C | 125 °C | Polyester Thermoplastic | Copper Alloy | 1 | DE E | 3 A | 4-40 | 8.08 mm | 0.318 " | 2 | Gold | Nickel Plated Steel | 9 | UL94 V-0 | Receptacle Female Sockets | Board Edge Right Angle Through Hole | 0.76 Ám | 30 Áin | Signal | D-Sub | Filter Mounting Brackets Shielded | Solder | ||
 EDAC Inc. | Black | -55 C | 85 °C | Polyester Thermoplastic | Copper Alloy | 1 | DE E | 3 A | Housing/Shell (M3) | 8.08 mm | 0.318 " | 2 | Gold | Nickel Plated Steel | 9 | UL94 V-0 | Receptacle Female Sockets | Board Edge Right Angle Through Hole | 0.38 µm | 15 µin | Signal | D-Sub | Filter Mounting Brackets Shielded | Solder | ||
 EDAC Inc. | Black | -55 C | 85 °C | Polyester Thermoplastic | Copper Alloy | 1 | DE E | 3 A | Housing/Shell (M3) | 8.08 mm | 0.318 " | 2 | Gold | Nickel Plated Steel | 9 | UL94 V-0 | Receptacle Female Sockets | Board Edge Right Angle Through Hole | 0.76 Ám | 30 Áin | Signal | D-Sub | Board Lock Mounting Brackets Shielded | Solder | ||
 EDAC Inc. | Black | -55 C | 125 °C | Polyester Thermoplastic | Copper Alloy | 1 | DE E | 3 A | 4-40 Mating Side Female Screwlock | 8.08 mm | 0.318 " | 2 | Gold | Nickel Plated Steel | 9 | UL94 V-0 | Receptacle Female Sockets | Board Edge Right Angle Through Hole | Signal | D-Sub | Filter Mounting Brackets Shielded | Solder | Flash | |||
 EDAC Inc. | Black | -55 C | 125 °C | Polyester Thermoplastic | Copper Alloy | 1 | DE E | 3 A | Housing/Shell (M3) | 8.08 mm | 0.318 " | 2 | Gold | Nickel Plated Steel | 9 | UL94 V-0 | Receptacle Female Sockets | Board Edge Right Angle Through Hole | 0.76 Ám | 30 Áin | Signal | D-Sub | Board Lock Mounting Brackets Shielded | Solder | ||
 EDAC Inc. | Black | -55 C | 85 °C | Polyester Thermoplastic | Copper Alloy | 1 | DE E | 3 A | 4-40 Mating Side Female Screwlock | 8.08 mm | 0.318 " | 2 | Gold | Nickel Plated Steel | 9 | UL94 V-0 | Receptacle Female Sockets | Board Edge Right Angle Through Hole | 0.38 µm | 15 µin | Signal | D-Sub | Mounting Brackets Shielded | Solder | ||
 EDAC Inc. | Black | -55 C | 125 °C | Polyester Thermoplastic | Copper Alloy | 1 | DE E | 3 A | Housing/Shell (M3) | 8.08 mm | 0.318 " | 2 | Gold | Nickel Plated Steel | 9 | UL94 V-0 | Receptacle Female Sockets | Board Edge Right Angle Through Hole | Signal | D-Sub | Board Lock Filter Mounting Brackets Shielded | Solder | Flash | |||
 EDAC Inc. | Black | -55 C | 125 °C | Polyester Thermoplastic | Copper Alloy | 1 | DE E | 3 A | Housing/Shell | 8.08 mm | 0.318 " | 2 | Gold | Nickel Plated Steel | 9 | UL94 V-0 | Receptacle Female Sockets | Board Edge Right Angle Through Hole | 0.76 Ám | 30 Áin | Signal | D-Sub | Mounting Brackets Shielded | Solder | 4-40 |
