801-93 Series
Manufacturer: Mill-Max Manufacturing Corp.
Beta
⌘K
CONN RCPT 48POS 0.1 GOLD PCB
| Part | Contact Finish - Mating | Contact Finish Thickness - Post | Contact Finish Thickness - Post | Mounting Type | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Insulation Color | Number of Positions Loaded | Material Flammability Rating | Insulation Material | Connector Type | Contact Finish - Post | Termination | Number of Rows | Insulation Height | Insulation Height | Contact Length - Post | Contact Length - Post | Operating Temperature [Min] | Operating Temperature [Max] | Number of Positions | Current Rating (Amps) | Pitch - Mating | Pitch - Mating | Contact Material | Contact Shape | Fastening Type | Contact Type | Number of Positions [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Mill-Max Manufacturing Corp. | Gold | 200 µin | 5.08 µm | Through Hole | 0.76 Ám | 30 Áin | Black | All | UL94 V-0 | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Receptacle | Tin-Lead | Press-Fit Solder | 1 | 0.276 in | 7 mm | 0.104 in | 2.64 mm | -55 C | 125 °C | 48 | 4.5 A | 0.1 " | 2.54 mm | Beryllium Copper | Circular | Push-Pull | Female Socket | |
Mill-Max Manufacturing Corp. | Gold | 200 µin | 5.08 µm | Through Hole | 0.76 Ám | 30 Áin | Black | All | UL94 V-0 | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Receptacle | Tin-Lead | Press-Fit Solder | 1 | 0.276 in | 7 mm | 0.104 in | 2.64 mm | -55 C | 125 °C | 5 | 4.5 A | 0.1 " | 2.54 mm | Beryllium Copper | Circular | Push-Pull | Female Socket | |
 Mill-Max Manufacturing Corp. | Gold | 200 µin | 5.08 µm | Through Hole | 0.76 Ám | 30 Áin | Black | All | UL94 V-0 | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Receptacle | Tin-Lead | Solder | 1 | 0.165 in | 4.2 mm | 0.125 in | 3.18 mm | -55 C | 125 °C | 26 | 4.5 A | 0.1 " | 2.54 mm | Beryllium Copper | Circular | Push-Pull | Female Socket | |
Mill-Max Manufacturing Corp. | Gold | 200 µin | 5.08 µm | Through Hole | 0.76 Ám | 30 Áin | Black | All | UL94 V-0 | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Receptacle | Tin-Lead | Solder | 1 | 0.165 in | 4.2 mm | 0.125 in | 3.18 mm | -55 C | 125 °C | 35 | 4.5 A | 0.1 " | 2.54 mm | Beryllium Copper | Circular | Push-Pull | Female Socket | |
 Mill-Max Manufacturing Corp. | Gold | 200 µin | 5.08 µm | Through Hole | 0.76 Ám | 30 Áin | Black | All | UL94 V-0 | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Receptacle | Tin-Lead | Solder | 1 | 0.165 in | 4.2 mm | 0.125 in | 3.18 mm | -55 C | 125 °C | 4.5 A | 0.1 " | 2.54 mm | Beryllium Copper | Circular | Push-Pull | Female Socket | 34 | |
 Mill-Max Manufacturing Corp. | Gold | 200 µin | 5.08 µm | Through Hole | 0.76 Ám | 30 Áin | Black | All | UL94 V-0 | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Receptacle | Tin-Lead | Solder | 1 | 0.272 in | 6.91 mm | 0.118 in | 3 mm | -55 C | 125 °C | 43 | 4.5 A | 0.1 " | 2.54 mm | Beryllium Copper | Circular | Push-Pull | Female Socket | |
 Mill-Max Manufacturing Corp. | Gold | 200 µin | 5.08 µm | Through Hole | 0.76 Ám | 30 Áin | Black | All | UL94 V-0 | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Receptacle | Tin-Lead | Solder | 1 | 0.276 in | 7 mm | 0.118 in | 3 mm | -55 C | 125 °C | 22 | 4.5 A | 0.1 " | 2.54 mm | Beryllium Copper | Circular | Push-Pull | Female Socket | |
Mill-Max Manufacturing Corp. | Gold | 200 µin | 5.08 µm | Through Hole | 0.76 Ám | 30 Áin | Black | All | UL94 V-0 | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Receptacle | Tin-Lead | Solder | 1 | 0.272 in | 6.91 mm | 0.118 in | 3 mm | -55 C | 125 °C | 9 | 4.5 A | 0.1 " | 2.54 mm | Beryllium Copper | Circular | Push-Pull | Female Socket | |
Mill-Max Manufacturing Corp. | Gold | 200 µin | 5.08 µm | Through Hole | 0.76 Ám | 30 Áin | Black | All | UL94 V-0 | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Receptacle | Tin-Lead | Solder | 1 | 0.276 in | 7 mm | 0.118 in | 3 mm | -55 C | 125 °C | 4.5 A | 0.1 " | 2.54 mm | Beryllium Copper | Circular | Push-Pull | Female Socket | 31 | |
Mill-Max Manufacturing Corp. | Gold | 200 µin | 5.08 µm | Through Hole | 0.76 Ám | 30 Áin | Black | All | UL94 V-0 | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Receptacle | Tin-Lead | Solder | 1 | 0.165 in | 4.2 mm | 0.125 in | 3.18 mm | -55 C | 125 °C | 59 | 4.5 A | 0.1 " | 2.54 mm | Beryllium Copper | Circular | Push-Pull | Female Socket |
