QGKF-200 Series
Manufacturer: Qualtek
Beta
⌘K
AC/DC CONVERTER 48V 200W
| Part | Current - Output 1 | Mounting Type | Operating Temperature [Max] | Operating Temperature [Min] | Number of Outputs | Voltage - Isolation | Type | Applications | Efficiency | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [x] | Features | Voltage - Output 1 | Power (Watts) | Approval Agency |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Qualtek | 4.2 A | Chassis Mount | 70 °C | -25 °C | 1 | 3000 V | Enclosed | ITE (Commercial) | 87.5 % | 99 mm | 1.97 " | 3.9 " | 7.83 in | 50 mm | 199 mm | Adjustable Output DC Input Capable PFC Universal Input | 48 V | 200 Watts | CB CE cURus |
 Qualtek | 16.7 A | Chassis Mount | 70 °C | -25 °C | 1 | 3000 V | Enclosed | ITE (Commercial) | 84 % | 99 mm | 1.97 " | 3.9 " | 7.83 in | 50 mm | 199 mm | Adjustable Output DC Input Capable PFC Universal Input | 12 V | 200 Watts | CB CE cURus |
