SRE6603 Series

Catalog

POWER INDUCTOR (SMD), 1.5 MH, 120 MA, SHIELDED, 35 MA, SRE6603 SERIES

Part	Frequency - Self Resonant	Mounting Type	Package / Case	Type	DC Resistance (DCR)	Inductance Frequency - Test	Material - Core	Inductance	Tolerance	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Operating Temperature [Max]	Operating Temperature [Min]	Current Rating (Amps)	Current - Saturation (Isat)	Shielding	Q @ Freq [custom]	Q @ Freq [custom]	DC Resistance (DCR) [Max]	Q @ Freq
Bourns Inc. SRE6603-152M	2 MHz	Surface Mount	Nonstandard	Drum Core Wirewound	4.2 Ohm	100 kHz	Ferrite	1.5 mH	20 %	0.26 in	4.45 mm	0.175 "	6.6 mm	105 ░C	-25 °C	120 mA	35 mA	Shielded	50	100 kHz
Bourns Inc. SRE6603-103M	800 kHz	Surface Mount	Nonstandard	Drum Core Wirewound		100 kHz	Ferrite	10 mH	20 %	0.26 in	4.45 mm	0.175 "	6.6 mm	105 ░C	-25 °C	0.02 A	17 mA	Shielded	50	100 kHz	32.8 Ohm
Bourns Inc. SRE6603-2R2M	120 MHz	Surface Mount	Nonstandard	Drum Core Wirewound		100 kHz	Ferrite	2.2 µH	20 %	0.26 in	4.45 mm	0.175 "	6.6 mm	105 ░C	-25 °C	1.8 A	920 mA	Shielded	40	200 kHz	50 mOhm
Bourns Inc. SRE6603-6R8M	50 MHz	Surface Mount	Nonstandard	Drum Core Wirewound		100 kHz	Ferrite	6.8 µH	20 %	0.26 in	4.45 mm	0.175 "	6.6 mm	105 ░C	-25 °C	1.2 A	580 mA	Shielded	40	200 kHz	65 mOhm
Bourns Inc. SRE6603-222M	2 MHz	Surface Mount	Nonstandard	Drum Core Wirewound		100 kHz	Ferrite	2.2 mH	20 %	0.26 in	4.45 mm	0.175 "	6.6 mm	105 ░C	-25 °C	100 mA	28 mA	Shielded	50	100 kHz	8.5 Ohm
Bourns Inc. SRE6603-151M	9 MHz	Surface Mount	Nonstandard	Drum Core Wirewound		100 kHz	Ferrite	150 µH	20 %	0.26 in	4.45 mm	0.175 "	6.6 mm	105 ░C	-25 °C	0.26 A	100 mA	Shielded			590 mOhm	40 100 kHz
Bourns Inc. SRE6603-331M	5 MHz	Surface Mount	Nonstandard	Drum Core Wirewound		100 kHz	Ferrite	330 µH	20 %	0.26 in	4.45 mm	0.175 "	6.6 mm	105 ░C	-25 °C	0.2 A	70 mA	Shielded			1.4 Ohm	40 100 kHz
